HAS VIDEO PLA Biodegradable Heating Shrink PE Film Blowing Machine For Bag , Agriculture Film

FOB Price

USD $12,000 - $14,000 / Set

1 Set(Min.Order)

Product Details

Condition:	New	Application:	Film	Plastic Processed:	PE
Blow Moulding Type:	Extrusion Blow Moulding	Automatic:	Yes	Place of Origin:	Zhejiang, China
Brand Name:	vinovo	Model Number:	SJ-60	Voltage:	220V
Power(W):	18.5kw	Dimension(LWH):	620030003200mm	Weight:	2.3T
Certification:	CE	Warranty:	1 Year	After-sales Service Provided:	Engineers available to service machinery overseas

SJ-60(70) Single-Screw Double Die Film Blowing Machine Set

Product Description

Features

The machine adopts single screw to extrude the material, two die heads to blow the film;
The screw stem and cylinder are made of 38CRMOALA high quality alloy steel after fine finshing and nitride treatment, which has high hardness, strong resistance to corrosion, durable service;
The die head is plated with hard chrome, of screw mandrel type structure with even and smooth discharging, the blown plastic film has fine finshing; the blower is of labyrinth structure with even air output;
The coiling unit adopts pressure friction rewinding or center rewinding, which is driven by torque motor, with even and smooths rewinding and easy roll changing.

Parameters

Model	SJ-60
Screw Diameter	Φ60mm
Reduced diameter of film	200-500mm
Single-face thickness of film	0.005-0.05mm
Max output	40-50kg/hr
L/D Length	28:1
Power of main motor	18.5kw
Rational speed of screw stem	10-120mm
Heating power	23kw
Outline diameter	620030003200mm
Weight	2.3T

Detailed Images

Samples

Certifications

Wenzhou T&D Packaging Machinery Factory: Contact nameWendy Zheng; Phone86-577-86288233; AddressNO.27 Yinquan Road,Anxia Village,Louqiao Town,Ouhai,Wenzhou, China Wenzhou,Zhejiang
