Home > Products > 6~12kv Voltage Transformer > JDZ(J)-10GY 10KV 11kv Single phase Outdoor type Voltage /Potential transformer
JDZ(J)-10GY 10KV 11kv Single phase Outdoor type Voltage /Potential transformer
USD $100 - $500
/ Piece
2 Pieces(Min.Order)
- 1000 Piece / Pieces per Month
- Ningbo port
- T/T
You May Like
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | SANAI | Model Number: | JDZ(J)-10GY |
| Usage: | Other, Measuring & protection | Phase: | Single | Coil Structure: | Toroidal |
| Coil Number: | Autotransformer |
Product Description
Product Description
JDZ(J)-10GY 10KV 11kv Single phase Outdoor type Voltage /Potential transformer
15kv outdoor & cast resin expoxy voltage transformer
1).Rated voltage :11kv
2).Max.system voltage :12kv
3),Rated insulation :7.2/20/60kv
4).voltage ratio: 7200/120V , or 8400/120V. or 8400/220V
5).Accuracy class: 0.5, 0.2, 3P , 6P
6),Rated burden : 10VA, 15VA , 20VA,30VA
7).two poloes
The other detail technical data ,please contact us .
we'd like to reply you in time .
