Acrel BA50L(II)-AI/V Smart AC Electrical Current Sensor Can be Widely Used in Industrial Automation Fields Out 1-5V/0-5V
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C
You May Like
-
Acrel Smart AC Electrical Transducer BA50(II)-AI/V Mainly Detects the Leakage Current of the Electrical System
-
Acrel Can be Widely Used in Industrial Automation Fields Smart AC Current Transformer BA20(II)-AI/V
-
Acrel Protector Digital Tube Display ALP300-5 Strong Anti-interference Ability, Stable and Reliable Work, Digital
-
Acrel Strong Anti-interference Ability, Stable and Reliable Work, DigitaL Digital Tube Display Smart Protector ALP300-25/C
-
Acrel Intelligent Protector ALP300-50/C Start-up Timeout, Overload, Underload, and Equalization Protection Digital Tube Display
-
Acrel Digital Tube Display ProtectorStrong Anti-interference Ability, Stable and Reliable Work, Digital,Intelligent ALP300-100/C
Product Description
Product Introduction
The intelligent BA series current sensor uses the principle of electromagnetic induction to measure the AC current in the power grid in real time and uses constant current and linear compensation technology to isolate and transform it into a standard DC signal output, or through the RS485 interface (Modbus-RTU protocol) to transmit the measurement data. DC24V or 12V safety voltage power supply, can be widely used in the field of industrial automation. BA50L(Ⅱ)-AI is an AC residual current transformer, which mainly detects the leakage current of the electrical system, can grasp the status of electrical circuits and equipment at any time, and prevent fires and other accidents caused by leakage.
Measurement - BA20(II)-AI Direct AC current measurement up to 200A - BA50(II)-AI Direct AC current measurement up to 600A - BA50L(II)-AI Leakage Current 0-1A - Overload: 1.2 times of rated value Application - Industrial automation
Features
