Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > 19 Inch CE DOCSIS 3.0 1U Chassis Cmts

19 Inch CE DOCSIS 3.0 1U Chassis Cmts

Name: 19 Inch CE DOCSIS 3.0 1U Chassis Cmts
Brand: Jinghong
SKU: 123225495

19 Inch CE DOCSIS 3.0 1U Chassis Cmts thumbnail-1

19 Inch CE DOCSIS 3.0 1U Chassis Cmts thumbnail-2

19 Inch CE DOCSIS 3.0 1U Chassis Cmts thumbnail-3

19 Inch CE DOCSIS 3.0 1U Chassis Cmts photo-1

19 Inch CE DOCSIS 3.0 1U Chassis Cmts photo-2

19 Inch CE DOCSIS 3.0 1U Chassis Cmts photo-3

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Chongqing, China

Brand Name:

Jinghong

Model Number:

JH-HE3416

Contact Supplier Request Quote Chat Now

Chongqing Jinghong High-Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

CHONGQING

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Chongqing, China

Brand Name Jinghong

Model Number JH-HE3416

Specifications

1.Compatible with DOCSIS2.0/3.0 standard cable modem
2.With high performance
3.Maximum of 160Mbps Data Rate
4.CE & RoHS

JH-HE3416 is one of a chassis CMTS with 19 inch 1U standard chassis, it is tailor made for head end room deployment. It is suitable for small broadband user’s scaled network. It has wide coverage and high efficiency.

There are three ways to manage it:

CLI after log in via serial port or by telnet;

Remote log in embed web NMS;

External NMS server based on SNMP protocols which run windows OS.

This items can compatible with DOCSIS3.0/2.0 cable modem.

Features

Compatible with DOCSIS3.0, C-DOCSIS standardwork with all cable modem based on DOCSIS, support both EURO DOCSIS and DOCSIS.
16 DS channels bound, 64/256/1024QAM modulation mode optional. Data rate could reach up to 1.1Gbps@1024QAM.
4 US channels bound, could be configured to QPSK, 3-8 grade QAM mode, data rate could reach up to 160Mbps.
Flexible on channels bound quantity set for operators convenient planning and use of channel resource.
Layer 3 routing functions, support static route, VLAN, NAT and DHCP relay agent.
There are GE RJ45 port and SFP on WAN port, convenient and flexible.
Built-in DHCP/TFTP server, support PPPoE.
Load balancing based on quantity of CM either DS or US.
Support IPV6, multicast function.
QoS based on service flow ensures bandwidth needs for various services.
Ensure network transmit safety via various kinds of methods such as BPI+, CM identification, anti-DOS attack , user isolation and IP source checking.
Support US channel spectrum analysis via Web and NMS management
Support three management ways: CLI after log in via serial port or by telnet; Remote log in embed web NMS; External NMS server based on SNMP protocols which run windows OS.

Specification

		Downstream		Upstream
		Euro- DOCSIS	DOCSIS
Modulation Mode		64QAM/256QAM/1024QAM		256QAM/64QAM/16QAM/QPSK
Frequency Range(MHz)		88~1000 adjustable	91~857 adjustable	5~65
Single channel bandwidth (MHz)		8	6	Single channel bandwidth (MHz)			6.4	3.2	1.6
Binding channel quantity		16		4
Max.total data bandwidth (Mbps)		1100	857	160
Single channel data rate(Mbps)	64QAM	41	27	Single channel data rate (Mbps)	256QAM		40.96	20.48	10.24
	256QAM	55	38		64QAM		30.72	15.36	7.68
Output level (dBmV)		10~60 adjustable 1 stepping			16QAM		20.48	10.24	5.12
					QPSK		10.24	5.12	2.56
				Receiving level (dBmV)			-13~+23	-13~+23	-13~+23
Single channel baud rate (Msymps)	64QAM	6.952	5.056941	Single channel baud rate (Msymps)			5.12	2.56	1.28
	256QAM	6.952	5.360537
RF port number		1		1
Reflection loss(dB)		> 14		> 14
Output impedance(ohm)		75		Input impedance (ohm)			75
Supported protocols		Euro-DOCSIS/DOCSIS3.0/2.0,TCP/IP,ARP,ICMP,VLAN,multicast,DHCP,TFTP,SNMP,PPPoE,DHCP relay agent,Telnet Etc.
Physical parameters
Network Port		1000M SFP fiber (SC/APC)		Input voltage		AC100~240V ,DC-48V customizable
		100M/1000M BASE-T		Consumed power		< 55 Watt
RF port		F type plug		Net weight		2.50Kg
Serial port		COM,baud rate of 115200bps,8bit data,none parity check and 1 stop bit		Working conditions		Temperature 0~40℃;humidity <90%
				Dimension		W430+44mm H48mm D290mm

Payment and delivery
Items will be shiped within 7 working days after T/T in advance via ups dhl fedex or ems etc.

Warranty

1 year for hardware repairing,5 years for software updating.
