Home > Products > Road Construction Machinery > Mini XCMG 4m Asphalt Pavers With Imported Engine RP403
Mini XCMG 4m Asphalt Pavers With Imported Engine RP403
- Shanghai
- T/T D/P D/A Money Gram Credit Card
You May Like
Product Details
| Condition | New | Production Capacity | 300 t/h | |
| Power(W) | 75000 | Max. Paving Thickness | 200mm | |
| Paving Width | 1.8m~4.2m | Place of Origin | Jiangsu, China | |
| Brand Name | XCMG | Model Number | RP403 | |
| Dimension(L*W*H) | 5535x1800x3580mm | Weight | 12.0t | |
| Certification | ISO,CE | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Mini XCMG 4m asphalt pavers with imported engine(DDE) RP403
Unit | Parameters | |
Basic paving width | m | 2.5 |
Max. paving width | m | 4.2 |
Max. paving thickness | mm | 200 |
Paving speed | m/min | 0~3.6 |
Travel speed | km/h | 0~11 |
Theoretical Productivity | t/h | 300 |
Hopper Capacity | t | 13 |
Gradeability | % | 20 |
Pavement evenness | mm/3m | 3 |
Transverse levelling accuracy | % | ±0.03 |
Centre crown ratio | % | 0~+3 |
Engine model |
| BF4M2012C |
Engine power | kW | 75 |
Engine speed | r/min | 2200 |
Machine weight | t | 12 |
Dimension | mm | 6400X2580X3830 |
Vibrator speed | r/min | 0~1470 |
Screed heating |
| Gas heating |
Auger and conveyor control |
| Automatic Control by Ultrasonic Sensors |
Automatic levelling control |
| Simulation control of electronic automatic leveler |
Items | Unit | Parameters |
Screed model | / | 475Q |
Type | / | Single vibrator+Gas heating |
Extension | / | Hydraulic+Mechanical assembly |
Width | m | 2.5~6.0 |
Vibrator speed | r/min | 0~1800 |
Vibrator amplitude | mm | 4 |
Extra-long screed | mm | 625 |
