Road Grader XCMG GR200 200hp Motor Grader

Name: Road Grader XCMG GR200 200hp Motor Grader
Brand: XCMG
SKU: 123225943
Availability: InStock

US$ 75,000 - 85,000 MOQ: 1 Set

Key Specifications

Condition:

New

Forward Speed(km/h):

Reverse Speed(km/h):

Shanghai Oriemac Machinery & Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Lianyungang

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Forward Speed(km/h) 38

Reverse Speed(km/h) 23

Place of Origin Jiangsu, China

Brand Name XCMG

Model Number GR200

Weight 16ton

Dimension(L*W*H) 8932*2625*3470mm

Certification ISO,CE

After-sales Service Provided Engineers available to service machinery overseas

road grader XCMG GR200 200hp motor grader

Basic specification
Engine model	D6114 ZG14B
Rated power/speed	147kW/2200rpm
Dimension(LxWxH)	8932×2625×3470mm
Operating weight(Standard)	16000kg
Performance specification
Travelling speed ,forward		5,8,11,19,23,38 km/h
Travelling speed ,reverse		5,11,23 km/h
Tractive force(f=0.75)		82KN
Max. gradeability		20%
Tire inflation pressure		260 kPa
Working hydraulic pressure		16 MPa
Transmission pressure		1.3~1.8MPa
Operating specification
Max. steering angle of front wheels		±50°
Max. lean angle of front wheels		±17°
Max. oscillation angle of front axle		±15°
Max. oscillation angle of balance box		15
Frame articulation angle		±27°
Min. turning radius using articulation		7.3m
Biade
Maximum lift above ground		450mm
Maximum depth of cutting		500mm
Maximum blade position angle		90°
Blade cutting angle		28°—70°
Circle reversing rotation		360°
Moldboard width X height		4270×610mm
