fly ash/ cement brick machines
- 5000 Set / Sets per Month
- Qingdao
- T/T
-
Hand press block making machine QTJ4-50
-
QTY10-15 ecological concrete bricks making machine
-
QTJ5-20 hollow bricks machine indian price
-
QTJ5-20 hollow brick machine,interlocking brick machine price
-
QTY10-15 hydraulic full automatic brick making machine for India
-
QTJ5-20 hollow brick machine,eco brick making machine
Product Details
| Condition: | New | Type: | Hollow Block Making Machine | Brick Raw Material: | Cement |
| Processing: | Brick Production Line | Method: | Hydraulic Pressure | Automatic: | Yes |
| Capacity: | 57600 Pieces / 8 hours | Place of Origin: | Henan, China | Brand Name: | YUJIE |
| Model Number: | QT10-15 | Voltage: | 380V or as your request | Power: | 36.8kw |
| Dimension(L*W*H): | 7200*2290*3100mm | Certification: | CE.SGS,ISO | Warranty: | 12 month |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
fly ash/ cement brick machines
Brick making machine automatically is a semi-automatic model that has developed on the basis of QT10-15 model, integrates the advantages of past small and medium-sized block molding machine. The aircraft uses four-pillar orientation, square steel rack; the bottom mold uses the directional vertical vibration mode. The machine equips with an air compressor, making the process of advance and retreat of upper module, material-discharging control use pneumatic, achieving the gas & electricity integrating control, therefore greatly enhance the productivity.
1, QT10-15 hydraulic block making machine main technical parameters
Parameter Name | Parameter values | |
The largest machine dimensions | 6600×1990×3000(L×W×H)(mm) | |
Rated pressure of hydraulic system | 21Mpa | |
Main vibration form | All vibration molded desk | |
Vibration frequency | 50~70Hz | |
Vibration acceleration | 10-15g | |
To adapt to the high brick | 50-200mm | |
Pallet size | Wooden | 830×660×(40±1)(mm) |
Iron | 830×660×(8-10±1)(mm) | |
Bamboo | 830×660×(15-20)(mm) | |
Molding cycle | 15-18 seconds 20-23 seconds to be added fabrics |
|
When production | Standard block (240×115×53mm) | 57,600 Pieces/ 8 hours |
Feeder capacity | Effective storage volume of 0.45m3 hopper | |
| Effective volume of 0.15m3 car charging | |
Machine power | 36.8kw | |
Machine weight | 12T | |
2, QT6-15 hydraulic block making machine specifications and the main product output of each plate
Model | Block Specifications (Mm) | Forming a number of | Molding cycle | Middle class | Host power |
QT6-15 | 390×190×190(block) | 6 | 15 | 11520 | 36.8 |
240×115×90(brick) | 15 | 15 | 28800 | ||
240×115×53(standard brick) | 30 | 15 | 57600 | ||
·This series of 150-650 tons of products with different specifications.·Brick shaped mold can be produced according to user needs. | |||||
QT6-15B hydraulic block making machine specifications and the main product output of each plate
Model | Block Specifications (Mm) | Forming a number of | Molding cycle | Middle class | Host power |
QT6-15B | 390×190×190(block) | 6 | 15 | 11520 | 36.8 |
240×115×90(brick) | 18 | 15 | 34560 | ||
240×115×53(standard brick) | 36 | 15 | 69120 | ||
·This series of 150-650 tons of products with different specifications. Brick shaped mold can be produced according to user needs. | |||||
Our Certification and Major Honors
ISO9001, CE,ISO,BV,SGS
China Well-known Trademark
China Top Enterprise
China Product Quality Trustworthy Enterprise
Our Quality and Reputation Proof
As reward and affirmation on our technology research capacity, our product quality and service we are honored with China Well-known Trademark, our product are honored with China National Trustworthy Quality Product as well as many other honors.
Our Service Clients
Our Clients includes those FORTUNE 500 companies like CHINA RAILWAY, CHINA SINOHYDRO, CHINA METALLURGY, CHINA STATE CONSTRUCTION ENGINEERING, CAMCE and China national top companies like CHINA SOUTH-TO-NORTH WATER PROJECT, CHINA MECHANICAL EQUIPMENT CORP etc.
Welcome to your inquiry for more technical advantage introduction of fly ash/ cement brick machines
...
