Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Henan, China | Brand Name | YUJIE | |
| Model Number | YHZS35 | Power(W) | 60kw | |
| Dimension(L*W*H) | 11m*4m*20 m | Weight | Configuration | |
| Certification | CE ISO TUV SASO | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
YHZS35 concrete batching plant
Zhengzhou Changli Machinery Manufacturing Co., Ltd. is one of the leading professional manufacturers and suppliers of Concrete Mixing/Batching Plant/Station, Stabilized Soil Mixing Station, Concrete Mixer, Concrete Batching Machine, Screw Conveyor, Cement Silo, Concrete Mixing Truck, concrete pump Tower Crane, Construction Elevator, etc. Meanwhile, we accept customization of steel products and supply relevant construction machinery. We are the Top 10 in China in Construction Enterprise Group.
Main Parameters
Characters
- Its discharge height is 3.8m, and it can mix various types of concrete;
- With the loader to feed material, it can store four types of aggregates at the same time and also with two cement silos and their respective screw conveyor;
- With electronic scales to measure and the mixing host is twin-horizontal-axis type;
- Electrical system is equipped with IPC, printer and so on to realize the centralized control and overall management;
Main technical data
Model | YHZS35 |
Rated Productivity | 35m3/h |
Main Mixer | JS750 |
Batching Unit | PLD1200 |
Max. Aggregate Diameter | 80mm |
Capacity of Aggregate Bin | 2×8m3 |
Aggregate Measuring and Conveying Mode | Belt Conveyer |
Measuring Scope & Accuracy of Aggregate | 1000Kg ±2% |
Measuring Scope & Accuracy of Cement | 300Kg ±1% |
Measuring Scope & Accuracy of Water | 150Kg ±1% |
Measuring Scope & Accuracy of Additives | 50Kg ±1% |
Mixing system
Batching machine
Control system
Cement silo and screw conveyor
