HZS25 concrete mixing plant 25m3 cement plant for sale
- 25 Set / Sets per Month
- Qingdao
- T/T
- hzs180 giant concrete batching plant complete concrete mixer plant on market
- complete set hzs180 big size concrete batching plant used for construction
- competitive price hzs180 concrete batching plant with sicoma mixer
- high performance 180m3/h capacity concrete batching plant with conveyor belt
- competitive low factory price concrete mixing batching plant for sale
- commercial concrete batching plant hzs120 mixing plant stationary for hot sale
Product Details
Condition: | New | Power Type: | Electric | Place of Origin: | Henan, China |
Brand Name: | YU JIE | Model Number: | HZS25 | Power(W): | 45kw |
Dimension(L*W*H): | 14.5m*5.6m*5.9m | Weight: | 25t | Certification: | CE, ISO |
Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
HZS25 concrete mixing plant 25m3 cement plant for sale
Main parts of HZS25 concrete plant:
1. JS500 twin-shaft concrete mixer;
2. PLD800 aggregate batcher;
3. welding type 50T or bolted type 100T cement silo;
4. Screw conveyor 219mm*8m;
5. water, cement and additive scales;
6. Air compressor;
7. Fully automatic computer control system with Omron PLC.
Specification of HZS25 concrete plant:
Item | Parameter |
Max. Productivity | 25 m3/h |
Nominal capacity of mixer | 0.5 m3 |
Max Weighing Value of aggregate | 1500kg |
Max Weighing Value of cement | 300kg |
Max Weighing Value of water | 150kg |
Max Weighing Value of additive | 40kg |
Rating transport capacity of screw conveyor | 35 |
Capacity of Cement Cabin | 50t |
Mixing Power | 18.5kw |
Hoist Power | 5.5kw |
Power of Machine | 60kw |
Weight of Machine | 25t |
Outline Dimension(LxWxH) | 15x8x14(m) |
Discharge Height | 3.8m |
Aggregate measuring accuracy | ≤2 % |
Water measuring accuracy | ≤1 % |
Cement measuring accuracy | ≤1 % |
Additive measuring accuracy | ≤1 % |
Detailed pictures:
JS500 concrete mixer
PLD800 aggregate batcher
welding type 50T cement silo (one set needs one 40HQ container)
Bolted type 100T cement silo (one set can be put into one 40HQ container)
Screw conveyor
water, cement and additive scales
concrete room
Fully automatic computer control system with PLC
1. products that we have
We are a manufacturer of concrete mixing plant, we have the following concrete mixing plants:
A. stationary concrete mixing plant: HZS25 (25m3/h); HZS35 (35m3/h); HZS50 (50m3/h); HZS60 (60m3/h); HZS75 (75m3/h); HZS90 (90m3/h); HZS120 (120m3/h); HZS180 (180m3/h); HZS240 (240m3/h);
B. mobile concrete mixing plant: YHZS25 (25m3/h); YHZS35 (35m3/h); YHZS50 (50m3/h); YHZS75 (75m3/h); YHZS100 (100m3/h)
2. our advantages:
A. we have CE,ISO,SGS and BV certificate;
B. we have 31-year experience;
C. we are a supplier of Lafarge;
D. we have over 500 workers to ensure quick delivery;
E. we have 20 engineers to design special concrete plants for our customers;
F. aftersales service: installation, debugging, operators trainning and spare parts supply.
3. Our certificates
CE, ISO, SGS and BV
4. Our factory
Factory gate
Concrete plant in our factory for exhibition
loading area for aggregate batcher and cement silo
Loading area for concrete mixer
1. Packaging
A. Three 40HQ containers will be needed;
B. A wooden-box with the size of 60cm*60cm*60cm will be used for small items like bolt, nult, screw etc.
2. Shipping
A. by sea or by train; we have rich experience of shipping by sea or by train;
1. installation, debugging, operators trainning;
2. maintanence:
A. when trainning your operators, our engineers will give them advice on how to operate the machines correctly;
B. we will send you the operation manual which can help you operate the machins properly, it can also help you to solve the common problems;
C.Call us at any time if you have problems about our concrete plants;
D.If needed, we will send engineers to your site to solve your problems.
2. providing some documents needed for your customs clearance, like commercial invoice, packing list, certificate of origin etc;
3. spare parts supply;
Related equipments we supply:
1. mobile concrete batching plant
Welcome to visit our factory at any time!!!
