2012 Good Quality Low Price Manual Paper Plate Machines

Specifications

1.Automatic fully dobule working station
2.Good machine includes whole process
3.It is an ideal paper plate equipment

KANG QI Paper Plate Forming Machine

<<<Welcome to our store !!!>>>

 Features

1.It is widely applied to make paper plate (or aluminum foil laminated paper plate) in round (rectangle, square, circular, or irregular) shape. Machine speed changes against the material (paper) thickness and the plate size.



2Standard ZDJ-40 Paper plate machine has two working stations; each station install one set of mold and each station have separately PLC digital control and electric control.



3.Model ZDJ-40 paper plate machine adopts high efficient pressurizing air cylinder, so that the Max. pressure can reach to 5T ,Compared with the oil pressure one, it has the advantages of high speed, environment protection and humanism design



4.The Machine was developed and researched in order to meet the market requirement. It has integrated the pneumatic and the mechanic technologies, which makes it has the functions of faster working speed, higher safety-performance, safer operation and easier maintenance than the conventional one.



QC Team:

more than 20 persons to check the machine's quality,every  machine need 1 week to make adjustment,ensure 100% qualitative product.

Contact:

We will reply you by Email or skype. Telephone within 24 hours,

you can call us anytime if you have any problem of our production.

shipment:

We will keep tracking with the container until clients receive it.

40HQ,40GP,20FT(LCL,FCL)

Specification:

Technical Specification:
Model	ZDJ-40 Automatic Paper Plate Forming Machine
Paper Plate Size	4—11 inch (mold exchangeable);
Raw Material	Paper/paperboard, Aluminum foil coated paper, One side PE coated paper or other;
Suitable paper weight	300-600 gsm (favorable weight: 350-450gsm)
Rated Productivity	15--25 piece/minute (total two stations,so two moulds is included)
Power Source	220V/380V 50Hz or other required
Total Power	2 KW
Total Weight	1000KG
Package Size (L x W x H)	1430mm x 1600 mmx 1900 mm
Working Air Source	Working pressure 0.8Mpa, Air out-put 1.5 m3/minute (need to buy Air comprssor);
If your plate is very large, and the paper is up 600gsm, we design a special machine for you
Pressurizing Air Cylinder Technical Specification
Air flow vlume		0.8 cubic/min
Air pressure		0.6-0.8Mpa
Air cylinder stroke		150mm
