Best price WT-A30 Paper Cup Sleeve Forming Machine
- NINGBO
- T/T Credit Card
You May Like
-
Best price WT-A30 ripple wrap hot cups machine
-
Best price WT-A30 ripple paper coffee cups machine
-
Best price WT-A30 ripple double wall paper cup machine
-
Best price WT-A30 Paper Cup Sleeve Wrapping Machine
-
Good price WT-RDM Direct Sleeve Paper cups machine
-
Good price WT-RDM disposable paper cup sleeve machine
Product Details
| Condition | New | Product Type | Paper Cup Machine | |
| Processing Type | Paper Folding Machine | Place of Origin | Zhejiang, China | |
| Brand Name | QC | Model Number | WT-A30 | |
| Voltage | 220V/380V 50Hz or other required | Power(W) | 4KW | |
| Dimension(L*W*H) | 2500 x 1250 x 2000 mm | Weight | 1000KG | |
| Certification | CE | Warranty | One year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Welcome to Wenzhou Qichen Industry & Trade Co.,Ltd.
Tel: 86-15706776450 Skype:wzqc006
Add: Room 101, Block B,Tongqian Lake, Qiaoli Village, Feiyun Street,Rui’an City,Zhejiang
First Quality, Best Service. We provide not only the products, but also the SOLUTION.
Description: Paper Cup Sleeve Forming Machine
WT-A30 Paper Cup Sleeve Forming & Wrapping Machine is a matching machine for paper cup machine,
It makes a second wall/sleeve around paper cup/bowl (the finished products are named double wall paper cup,
or sleeve paper cup).
It makes double wall paper cup/bowl after running a whole procedure of :
# Automatic sleeve-paper (fan-sleeve) feeding,
# Sleeve-cone-body welding (by ultrasonic wave),
# Cone-sleeve bottom folding (for hollow-style sleeve cups only),
# Water-glue(POLYVINYL ACETATE EMULSION) spraying (spray glue inside the cone-sleeve),
# Cup/bowl feeding (absorb/suck white-cup into the cone-sleeve),
# Inserting and bonding sleeve to the cup,
# Collecting, and with the function of photo electric detection, fault alarm, and count.
Technical Specification: Paper Cup Sleeve Forming Machine
Paper Cup Size: | 5oz~16oz cup; 20oz~50oz bowl (mold exchangeable) |
Raw Material: | PE coated paper, Gloss printed paper (gray based paper with gloss printing), other film coated paper (can be welded by ultrasonic) |
Suitable paper weight: | 170~450gsm |
Rated Speed: | 40~50 cups/minute |
Power Source: | 220V/380V 50Hz, (Better use 380V 3-phase) |
Total Power: | 4KW |
Total Weight: | 1000KG |
Pack Size (L*W*H) | 2500 x 1250 x 2000 mm |
Working Air Source: | Air pressure:0.3Mpa; Air Out-put:0.6m³/minute |
Sleeve Side Welding: | Ultrasonic |
Sleeve and Cup bonding: | Water-glue (POLYVINYL ACETATE EMULSION) |
Packaging&Shipping: Paper Cup Sleeve Forming Machine
Company information
Our Services: Paper Cup Sleeve Forming Machine
The good should be of good quality. But another important thing is the after service. Machines are machine, so they will have problems, even small problems. It is hard for customers to solve all the problems.
Our company will provide you good after services. We can help you solve the problem through video, email, phone. 24 hours hot line.
If needed, we can also let our engineer go to your country to solve the problem. We hope all the customer will satisfied with our machine and services.
If you are interested in our machines or have any questions,pls feel free to contact me .
Contact: Lin
Phone/viber/whatsapp: 86-15706776450
Email:info06@
Skype: wzqc006
Fax: 86-0577-65565872
Tel: 86-0577-65566111
Company :Wenzhou QiChen Industry & Trade Co., Ltd.
