Specifications
smt reflow oven t962a- 300*320mm soldering area
- SMT,SMD,LED,PCB soldering
- Factory price
smt reflow oven, puhui t962a, automatic pcb soldering machine, infrared ic heater,taian
Technical parameters T962A
Soldering area: 300*320mm
Overall dimensions: 43*37*26cm
Packing dimensions: 51*45*33cm
Power: 1500W
Cycle time: 1-8 min
Voltage: AC110V-AC220V /50-60HZ
Net weight: 12.5Kgs
Gross weight: 15Kgs
Micro-processor controlled reflow oven, suit for various soldering of SMD/BGA automatically, easy operate; Fast infrared and hot air heating, make temperature more accurate and evenness. Fuzzy temperature control technology, visualization drawer, can see the whole soldering process very clearly. It can achieve soldering of single and double-sides PCB board.
FEATURES
(1) Infrared soldering area: 300*320mm (T-962A)
(2) Eight soldering waves
(3) Special heat up and temperature equalization
Big power of energy efficient Infrared heating and air circulation to re-flow solder.
(4) Ergonomic design, practical and easily operated
(5) Large number of available functions
Solder most single or double-sides PCB boards, for example CHIP, SOP, PLCC, QFP, BGA etc. It is the ideal rework solution from single runs to on-demand small batch production.
Choose wave according to your solder paste
we provide eight different waves, please choose one according to your request. Press the F1/F2 to choose different wave, press F3 to look into different wave parameter, press 4 to confirm the wave you chose.
Wave one for 85Sn/15Pb 70 Sn/30Pb
Wave two for 63Sn/37Pb 60 Sn/40Pb
Wave three for Sn/Ag3.5; Sn/Cu 75 Sn/Ag4.0/Cu.5
Wave four for Sn/Ag2.5/Cu.8/Sb.5; Sn/Bi3.0/Ag3.0
Wave five with the red gum standard is solid to turn temperature wave,Heraeus PD955M.
Wave six & seven & egiht with The PCB circuit board returns to fix etc.
Wave seven & eight, set-up by yourself.
Warranty
Warranty – the main body maintains for one year and the spare parts maintains for three months.
Service – provide the immediate network online Q/A and the technical advisory work service
Delivery
Safe packing and fast delivery by air express.
We are the ONLY and ORIGINAL manufacturer – Taian Puhui
Please contact us for good price and more details
Skype : kellyzhang2
Trademanager : cntech168
QQ: 2406360635
Cell: 86 18865488826
Or send inquiry to us
Hope to cooperate with you, thank you
Ms.Kelly
Overseas Marketing Manager
