Specifications
infrared ic heater T962A- Infrared heating ,Eight waves
- Original manufacturer
- Factory price supply
- CE
t962a, desktop reflow oven,puhui t962a infrared ic heater,small wave soldering machine,led soldering machine,taian puhui
Taian Puhui Electric Technology Co., Ltd
Original manufacturer
Made in China
(1). Have big infrared soldering max area:
Soldering area to reach effectively: 300×320mm, Increase the usage scope of this machine consumedly, economical investment.
(2) Many temperature wave choice for you.
Memory eight kinds of temperature parameter waves can be provided as choice, and establish to move heating and cool off function compulsory; Whole soldering process to complete automatically, easy to use.
(3) Special heat up and temperature equalization with all design.
Output the power reaches to a 1500 W, Adoption fast infrared radiation and circulation the wind for heat, so the temperature is very Accurate and even, Whole soldering process to complete automatically for you choice temperature parameter waves.
(4). Humanized science and technology exquisite article.
Firm of external appearance, can see of operation, amity of person machine operation interface, the perfect temperature wave project, from start to eventually body science and technology now is originally;
The agile physical volume and weight, let you economize a great deal of money, the set noodles type places mode, can let you own larger space; Simple operating instructions, let you a see can use.
(5) Perfect function choice.
Return soldering, drying, heat preservation, finalize the design, fast cool off etc.can use Can soldering the most smart small part example CHIP,SOP,PLCC,QFP,BGA etc; Can used to the gum of the product solid turn, the circuit board is hot aging, the PCB plank maintains to wait various works.Be applicable to each kind of business enterprise, company extensively develop and the small batch quantity produce a demand.
Want to know more information, don't hesitate, please contact me as soon as possible
Ms.Kelly trademanager : cntech168 Skype: kellyzhang2
Technical parameters T962A
Soldering area: 300*320mm
Overall dimensions: 43*37*26cm
Packing dimensions: 51*45*33cm
Power: 1500W
Cycle time: 1-8 min
Voltage: AC110V-AC220V /50-60HZ
Net weight: 12.5Kgs
Gross weight: 15Kgs
962/962A/962C
Choose wave according to your solder paste
we provide eight different waves, please choose one according to your request. Press the F1/F2 to choose different wave, press F3 to look into different wave parameter, press 4 to confirm the wave you chose.
Wave one for 85Sn/15Pb 70 Sn/30Pb
Wave two for 63Sn/37Pb 60 Sn/40Pb
Wave three for Sn/Ag3.5; Sn/Cu 75 Sn/Ag4.0/Cu.5
Wave four for Sn/Ag2.5/Cu.8/Sb.5; Sn/Bi3.0/Ag3.0
Wave five with the red gum standard is solid to turn temperature wave,Heraeus PD955M.
Wave six & seven & egiht with The PCB circuit board returns to fix etc.
Wave seven & eight, set-up by yourself.
