Help CenterMINI LASER CUTTER 6040
Related Products
Specifications
MINI LASER CUTTER 60401 Stable structure
2.CE standard
3.High speed and precision, good stability
4.Easy control
| ||
Machine Description |
EXLAS-6040 Laser Engraving and Cutting Machine |
|
Machine Performance: | ||
Laser-type |
Hermetic and detached CO2 laser tube |
|
Laser-power |
60W |
|
Cooling Mode |
Circulating-water-cooling |
|
Power Adjustment |
0-100% controlling, no segment and adjusting by software |
|
Machine Control and Drive |
Speedy DSP controlling, stepper motor |
|
Max Engraving Speed |
60000mm/min |
|
Max Cutting Speed |
300mm/min(when cutting 10mm thick of acrylic) |
|
Repeating Location |
0.01mm |
|
Minimum Character |
Chinese character 1.5mm, crisscross-row 1mm |
|
Max Power |
750W |
|
Adjustable Up-down Distance of Laser Head |
30mm |
|
Working Travel Area |
600x400mm, 600mm width with infinity material-feeding |
|
Table Area |
650x950mm |
|
Up-down Range of Working Table |
Mechanical 280mm |
|
Working Voltage |
AC220V 50Hz |
|
Working Environment |
Temperature: 0-45¡æ, Humidity: 5%-95%, and congeal-water removed |
|
Controlling Software Language |
English, Simplified Chinese, Traditional Chinese and procuring of multi-languages |
|
Dictate Format |
*.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*las, Support AutoCAD,CoreDraw direct outputting |
|
Body Dimension (LxWxH) |
1480x880x900mm |
|
PackagingDimension (LxWxH) |
1640x1020x1060mm |
|
Packaging |
Wooden box |
|
Gross Weight |
140kg |
|
Machine Color |
Customizable |
|
Delivery Time |
10 days |
|
Payment |
T/T |
|
Optional Equipment |
Rotary attachment |
|
Motorized up-down table |
||
Water-cooling unit |
||
Red-light position |
||
Vacuum table |
||
DSP Off-line operation with usb flash |
||
