Specifications
Laser milling Machine New EXLAS-6040 :1.Door switches
3.Temperature control
4.CE standard
5 handy design
Detailed Product Description
Machine Description | EXLAS-6040 Laser Cutting Machine |
Machine Performance: | |
Laser-type | Hermetic and detached CO2 laser tube |
Laser-power | 60W |
Cooling Mode | Circulating-water-cooling |
Power Adjustment | 0-100% controlling, no segment and adjusting by software |
Machine Control and Drive | Speedy DSP controlling, stepper motor |
Max Engraving Speed | 60000mm/min |
Max Cutting Speed | 500mm/min(when cutting 10mm thick of acrylic) |
Repeating Location | 0.01mm |
Minimum Character | Chinese character 1.5mm, crisscross-row 1mm |
Max Power | 750W |
Adjustable Up-down Distance of Laser Head | 30mm |
Working Travel Area | 600x400mm, 600mm width with infinity material-feeding |
Table Area | 650x950mm |
Up-down Range of Working Table | Mechanical 280mm |
Working Voltage | AC220V 50Hz |
Working Environment | Temperature: 0-45¡æ, Humidity: 5%-95%, and congeal-water removed |
Controlling Software Language | English, Simplified Chinese, Traditional Chinese and procuring of multi-languages |
Dictate Format | *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*las, Support AutoCAD,CoreDraw direct outputting |
Body Dimension (LxWxH) | 1480x880x900mm |
Packaging Dimension (LxWxH) | 1640x1020x1060mm |
Packaging | Wooden box |
Gross Weight | 140kg |
Machine Color | Customizable |
Delivery Time | 15 days |
Payment | T/T |
Optional Equipment | Rotary attachment |
Motorized up-down table | |
Water-cooling unit | |
Red-light position | |
Vacuum table | |
DSP Off-line operation with usb flash | |
The development for new EXLAS series laser machine:
1, The new Humanity design makes the machine body more compact and saves working space.
2, Improved structure enable the machine working more stable and better accuracy, and lower noise.
3, Intelligentized safty switch on door openning and closing, when you open the door, the machine stop beaming and travelling, you can resume working manually or by closing the top door.
4, Intelligentized thermostat and water flowing switch to protect the laser tube, when the temperature goes above a certain point (can be fixed), the machine will pause and resume till the temperature get normal, when there is no water flowing, the switch will close and machine stop working. this enable the laser tube using lifespan to be extended.
Guarantee & Aftersales Service:
Laser tube 8000-10000 hours' working time
Comprehensive guarantee for half year
24-hour technical support by email or calling
User-friendly English manual for machine using and maintaining
