EXLAS Laser Etching Machine1280 New Version

Specifications

New Version Laser Cutter EXLAS1280:

1) Working Travel Area: 1200 x 800mm,1250mm width with infinity material-feeding

2) Laser power: 80W (150W for option)

3) Laser type: carbon dioxide laser tube

4) Max Engraving speed: 1,200mm/s

5) Max Cutting speed: 500mm/min (80w, 10mm thick of acrylic)

6) Resetting positioning accuracy: <0.015mm

7) Cutting depth: acrylic 0-25mm

8) Min. shaping character: Chinese character 1.5mm, crisscross-row 1mm

9) Power supply: 220V±10% 50Hz or 110V±10% 60Hz

10) Gross power: 1,800W

11) Software supported: ArtCut, CorelDraw, PhotoShop, AutoCAD

12) Graphic format supported: *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*las, Support

13) Engraver for curve surfaces: we can add a Rotary attachment on the laser engrave/cutting machine, then the machine can engrave on cylinder

14) Circulating-water-cooling: yes

15) Up-down Range of Working Table: Mechanical 260mm (up and down by hand)

16) Laser tube (life hours): 10,000hours

17) Equipment dimensions (mm): 1800x1180x1100mm

18) Assistant equipment: water pump, exhaust fan, aluminum alloy worktable

19) Optional spare parts: Rotary system, Motorized up-down table, Cooling water system, Red-light position, DSP Off-line operation with usb flash

20) Recommended spare parts / consumables: laser tube and lens

21) English LCD

22) USB interface

23) Supports CAD and CorelDraw output directly

1 The new Humanity design makes the machine body more compact and saves working space.

2  Improved structure enable the machine working more stable and better accuracy, and lower noise.

3 Intelligentized safty switch on door openning and closing, when you open the door, the machine stop beaming and travelling,you can resume working manually or by closing the top door.

4 Intelligentized thermostat and water flowing switch to protect the laser tube, when the temperature goes above a certain point (can be fixed), the machine will pause and resume till

the temperature get normal, when there is no water flowing, the switch will close and machine stop working.this enable the laser tube using lifespan to be extended.

5 LED lamps also fixed, long lifespan and safe position
