Specifications
Crane/truck crane takes Weichai engine, streamline cabin, self-developed chassis 8x4 drive, Hydraulic Motor .
(2)The crane adopts WEICHAI Steyr engine which is specially developed for cranes that often travel at low speed. This kind of engine not only can produce large output torque, but also has excellent starting performance and good grade-ability.
(3)The crane is equipped with 9-shift gearbox which has smooth performance and simple structure, and facilitated maintenance.
(4)The crane is fitted with a 42m long hexagon boom made with high-strength steel, which has strong resistance of bending and torsion. The distinctively-designed circular arc sliding block (having obtained a national patent) makes the stress distributed evenly.
(5) The telescopic boom improves the stability of crane when it works with large working radius. (When boom telescopes in different sequence, the position of booms centre of gravity is adjusted accordingly.)
(6)The slewing mechanism can efficiently prevent the crane from overloading.
(7)The 5th outrigger is fitted with warning device (acoustic alarm), which can help operator operate a crane safely.
Item | Value | Remarks | ||
Working performance specification | Max. Rated total lifting capacity(kg) | 55000 |
| |
Max. Load moment of basic boom (kn.m) | 1764 | 1470 (outrigger beam half extended) | ||
Max. Load moment with max. Main boom length (kn.m) | 940.8 | 793.8(outrigger beam half extended) | ||
Max. Lifting height of basic boom (m) | 11.6 |
| ||
Max. Lifting height of main boom(m) | 42.1 | Deformation of boom is not taken into consideration | ||
Max. Lifting height of fly jib(m) | 58.3 | |||
Working speed | Max. Speed of single rope on main winch (m/min) | 130 | The 4th layer of drum | |
Max. Speed of single rope on auxiliary winch (m/min) | 72 | The 2nd layer of drum | ||
Derricking time of boom (s) | 50 |
| ||
Telescopic time of boom (s) | 95 |
| ||
Slewing speed (r/min) | 02 |
| ||
Traveling specification | Max. Traveling speed (km/h) | 76 |
| |
Max. Grade-ability % | 32 |
| ||
Min. Turning circle diameter (m) | 24 |
| ||
Min. Ground clearance (mm) | 260 |
| ||
Limits for exhaust pollutants and smoke | Comply with related standards | Gb3847-2005 Gb17691-2005 (stage iii) | ||
Oil consumption per hundred kilometers (l) | 40 |
| ||
Mass specification | Deadweight of crane in traveling condition (kg) | 40400 |
| |
Complete vehicle kerb mass (kg) | 40200 |
| ||
Front axle load (kg) | 14900 |
| ||
Rear axle load (kg) | 25500 |
| ||
Dimension specification | Overall dimensions(l×w×h)(mm) | 13300×2750×3550 |
| |
Base on outriggers (m) | 5.92 |
| ||
Distance between outriggers (m) | Full extended 6.90 Half extended 4.70 |
| ||
Main boom length (m) | 11.142.0 |
| ||
Main boom angle° | -280 |
| ||
Fly jib length(m) | 9.5, 16 |
| ||
Offset angle of fly jib ° | 0 , 30 |
| ||
Chassis | Model | Zlj5401 |
| |
Class | Ii |
| ||
Engine | Model | Wp10.336 |
| |
Rated power (kw/r/min) | 247/2200 |
| ||
Max. Output torque (n.m/r/min) | 1250/12001600 |
| ||
Manufacturer | Changsha zoomlion | |||
