Truck Crane ( Lifting Capacity: 25t )

Name: Truck Crane ( Lifting Capacity: 25t )
Brand: XCMG
SKU: 122879679
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Max. Lifting Load:

25T

Place of Origin:

Jiangsu, China

Shanghai Longji Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Max. Lifting Load 25T

Place of Origin Jiangsu, China

Brand Name XCMG

Model Number QY25A

Specifications

truck crane ( lifting capacity: 25t )

Classificatory	Item		Unit	Parameter
Engine	Model		D6114ZLQ5B
Outline dimension	Overall length		mm	12380
	Overall width		mm	≤2500
	Overall height		mm	3500
	Wheel base	Axle 1, Axle 2	mm	4325
	Wheel base	Axle 2, Axle 3	mm	1350
	Track	Front wheel	mm	2090
	Track	Rear wheels	mm	1865
Mass	Total mass in travel state		kg	28000
	Axle load	Front axle	kg	6435
	Axle load	Mid and rear axle	kg	21565
Travel performance	Travel speed	Max. travel speed	km/h	≥72
	Travel speed	Min. stable travel speed	km/h	≤3
	Turning diameter	Min. turning diameter	m	≤21
	Turning diameter	Min. turning diameter at boom tip	m	≤25
	Min. ground clearance		mm	270
	Approach angle		(°)	21
	Departure angle		(°)	11
	Braking distance (at 30km/h with full load)		m	9.5
	Max. grade-ability		％	24
	Fuel consumption for 100km		L	38

Main Technical Data for Lifting Operation

Classificatory	Item				Unit	Parameter
Lifting performance	Max. total rated lifting capacity				t	25
	Min. rated working radius				m	3.5
	Turning radius at turntable tail				m	≤3.06
	Max. load moment		Base boom		kN.m	932
			Fully extended boom		kN.m	488
			Fully extended boom + Jib		kN.m	162
	Outrigger span		Longitudinal		m	5.07
			Lateral		m	5.4
	Lifting height		Base boom		m	≥9.9
			Fully extended boom		m	≥24.8
			Fully extended boom + Jib		m	≥32
Working speed	Boom raising time				s	≤72
	Boom full extension time				s	≤115
	Max. swing speed				r/min	3
	Hoist speed (Single line)	Main winch		Full load	m/min	≥67
				No load	m/min	≥120
		Aux. winch		Full load	m/min	≥42.8
				No load	m/min	≥76.5
Noise limit	Crane exterior noise				dB (A)	≤120
	At seated position				dB (A)	≤90
