PCB Dual Magazine Line Loader&unloader
Negotiable
1 (Min. Order)
You May Like
Product Details
| Place of Origin | China | Brand Name | SAM | |
| Model Number | SMD-1D100M2G |
Product Description
Features:
- SMT production lines for dual an rear respectively to send and receive two tracks of the PCB.
- Controlled by PCL.
- User freindly soft touch LED menbrane control panel.
- Pressure regulated on pusher's to prevent board damage.
- Three points pneumatic clamping to align and secure magazine in position .
- The pusher height can be adjusted according to PCB thickness.
- SMEMA compatible.
Technique Parameter
| Description | SMT production lines with dual and rear |
| Amount of magazine | Upper conveyor:1;Lower conveyor:1 |
| Time feed PCB | Approx. 6 seconds or specify |
| Magazine change time | Approx. 30 seconds or specify |
| Indexing pitch | 10,20,30,40 mm or specify |
| Power source | 230VAC 1ph 500VA max (option 100VAC) |
| Air pressure&Consume | 4-6 bar,20ltr/min max |
| PCB Thickness | 0.6 mm min |
Specification Parameter
| Machine Name | Model | Size | Dimension(L*W*H)(mm) | Effective PCB Size(mm) | Approximate Weight(kg) | Rack Size(L*W*H)(mm) |
| Loader | SMB-1C300M2G | M | 1450*1550*1250 | 50*50-330*250 | 220 | 335*320*560 |
| SMB-1C300L2G | L | 1650*1780*1250 | 50*50-445*330 | 320 | 460*400*560 | |
| SMB-1C300LL2G | LL | 1980*1900*1250 | 50*50-530*390 | 380 | 535*460*570 | |
| SMB-1C300XL2G | XL | 1980*2150*1250 | 50*50-530*460 | 460 | 535*530*570 |
| Machine Name | Model | Size | Dimension(L*W*H)(mm) | Effective PCB Size(mm) | Approximate Weight(kg) | Rack Size(L*W*H)(mm) |
| Unloader | SMB-1D100M2G | M | 1450*1550*1250 | 50*50-330*250 | 220 | 335*320*560 |
| SMB-1D100L2G | L | 1650*1780*1250 | 50*50-445*330 | 320 | 460*400*560 | |
| SMB-1D100LL2G | LL | 1980*1900*1250 | 50*50-530*390 | 380 | 535*460*570 | |
| SMB-1D100XL2G | XL | 1980*2150*1250 | 50*50-530*460 | 460 | 535*530*570 |
