0.9mm 1.5M Mini Type SC UPC 1x16 Optical Splitter
US$ 15 - 20
MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
Splitter
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHNE
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cassette Type SC/APC 1:8 PLC Fiber SplitterNegotiableMOQ: 10 Pieces -
ABS PLC Splitter Box 1x16 PLC Fiber Optic Splitter In ABS BoxNegotiableMOQ: 10 Pieces
-
Cassette Type 1M 2.0mm 1x8 PLC Splitter ModuleNegotiableMOQ: 10 Pieces
-
Cassette Type ABS SC/APC 1x16 PLC SplitterNegotiableMOQ: 10 Pieces
-
Cassette Type 1M 2.0mm 1x32 PLC Splitter ModuleNegotiableMOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
OEM
Model Number
Splitter
0.9mm 1.5M Mini type SC UPC 1x16 optical splitter
1x16 optical splitter Feature
1.Good uniformity and low insertion loss
2.Low Polarization Dependent Loss
3.Stability Telecordia GR-1221 and GR-1209
4.Components through TLC-Certified,Conform to YD1117-2001
5.Operating environment: -40ºC to +85ºC
6.High Polarization Extinction Ratio & Excellent Uniformity
7.G.657A Fiber
8.Good channel-to-channel uniformity
1x16 optical splitter Parameter
1*N Blockless Fiber PLC Splitter
| Parameter | Unit | configuration | |||||||||||
| Mode | 1*2 | 1*3 | 1*4 | 1*6 | 1*8 | 1*12 | 1*16 | 1*24 | 1*32 | 1*64 | 1*128 | ||
| Operate Wavelength | nm | 1260~1650 | |||||||||||
| Insertion Loss | Typ. | db | 4.0 | 6.0 | 7.0 | 9.4 | 10.0 | 12.0 | 13.2 | 16.0 | 16.5 | 20.5 | 24.5 |
| Max. | db | 4.3 | 6.2 | 7.4 | 9.8 | 10.7 | 12.5 | 13.9 | 16.5 | 17.2 | 21.5 | 25.5 | |
| Uniformity | db | 0.5 | 0.6 | 0.8 | 0.8 | 1.0 | 1.0 | 1.4 | 1.5 | 1.6 | 2.0 | 2.6 | |
| PDL | db | 0.2 | 0.2 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.5 | 0.8 | |
| Directivity | db | ≥55/50 | |||||||||||
| Operate temperture | ℃ | -40~+85 | |||||||||||
1x16 PLC Splitter Applications
1.Fiber to the point (FTTx)
2.Fiber to the home (FTTH)
3.Passive optical networks(PON, GEPON)
4.Local area networks (LAN)
5.Cable television (CATV)
6.Test equipment
