solar charge controller KT1215P

Specifications

Features

12V/24V Adaptive

LED digital display

3-stage charging

PWM pulse modulation charging technology

Can be set light controlled and 1-13 hour timed

Electronic protection

A key set, simple operation

Specifications:

1.M fast charging,LED
2.U smart control
3.V/24V auto adapt,10A
4.ght+(1-13)hours time control


  Warranty:1 year

Delivery time:3-5 days for sample

Universal solar charging lights controller can be customized solar 5A-40A 12v/24V

15A MOS backing, thermally enhanced

Using Infineon originally imported MOS conduction ultra small pressure drop, heat ultra-small

Main features:

1, the use of a microcontroller and dedicated software, intelligent control;

2, using the battery discharge rate characteristic correction accurate discharge control. The discharge end voltage is corrected by the discharge rate curve control points, eliminating the purely voltage control over discharge inaccuracies found battery inherent characteristics, i.e. different discharge rate has a different end voltage.

3, with over charge, over discharge, electronic short circuit and overload protection, a unique anti-reverse protection automatic control; the above protection not damage any parts, do not burn Insurance;

4, with a tandem PWM charging main circuit voltage loss than the use of diode charging circuit is reduced by nearly half of the charging circuit, charging efficiency than non-PWM high 3% to 6%, increase electricity; enhance the over-discharge recovery charging, normal direct charge, the float automatically controlled manner so that the system consists of a longer life; same time with a high-precision temperature compensation;

5, the intuitive LED light tube indicates the current battery status, allow users to understand the conditions of use;

6, all controlled using industrial-grade chips (only with I industrial grade controller) in cold, hot, humid environment to run freely. A crystal oscillator timing control, precise timing control.

7, the abolition of the potentiometer to adjust the control setpoint, and the use of the E side memory record of working control point, the settings digitized, eliminating the control point potentiometer vibration deviation, drift errors reduce the accuracy, reliability factors;

8, using a digital LED display and settings, one-button operation to complete all settings, and extremely easy to use and intuitive.

9 sealed waterproof (-S) has a completely waterproof and moisture resistant.
