Specifications
Agricultural Mulch Plastic Film MachineMulch Plastic Film Machine
Plastic Machinery
Main Technical Paremeters
SJ65-FMS1500N Film Blowing Machine
Suitable Material: HDPE, LDPE, LLDPE
Film width: LDPE:1400MM,HDPE:1300MM
Film thickness:LDPE: 0.020~0.20mm,HDPE:0.015-0.12mm
Max. Extrusion Output:LDPE: 110kg/h,HDPE:90KG/H
Gear Box: 3 Axis, Steel Nitride Harden Gears with Oil lubrication pump.
Material of screw and barrel: Alloyed high-quality steel 38CrMoAlA with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment.
Whole power of machine: ~80KW
Weight: 5200KG
Outline diameter (L*W*H):6.7m x3.2m x7.0 m
*) EXTRUDER:
Screw diameter : φ65mm
Screw L/D Length: 30:1
Screw material: 38 CRMOALA
Cylinder material: 38 CRMOALA
Main Motor: 37 KW (controlled by Inverter)
*) TYPE OF DIE
Die size :(HDPE)φ90mm, φ120mm (LDPE) φ350mm
Air ring: Single air ring and wind gap
Heater Capacity: LDPE:9.95kw ,HDPE:6.1KW
Air Cooling Power: 5.5kw
*) TAKE-UPUNIT
Take-up unit: controlled by Inverter Motor
Roller width: 1500mm
Driving motor: 2.2kw
Wooden plank bubble supports and A-frame with Gusset device
*) WINDER UNIT
Winder Type: Single Manual winder
Winding motor: 4.4 KW
Winding speed: 10-50m/min
Temperature Control: 6 points
