FEATURES:
1. The machine is used to produce the mulch plastic film, agricultural film and outer package film made of LDPE, HDPE, LLDPE and MLLDPE. It employs some new technologys like the most advanced heat running technology and special wind ring that is used to extrude the shaped mulch plastic film.
2. The machine is designed reasonably and elegantly. It is small and is easy to operate and maintain. The product features with good plasticization, high physical and mechanical performance and strong tear resistance.
3. With advanced technology and reasonable accessories, the machine is featured by high output, low energy consumption, good stability and reliability etc. Therefore, it is the ideal equipment to agricultural mulch plastic film in the new century.
MAIN TECHNICAL PARAMETERS:(SJ65-FMJ1500N)
1) LAYER NUMBER: one layer
MAX. FILM WIDTH: 1400mm LD 1300mm HD
FILM THICKNESS: 0.0020-0.20 mm
RAW MATERIAL: HDPE, LDPE, LLDPE
Output: 110kg/h LD 90kg/h HD
2) EXTRUDER:
SCREW DIAMETER: Φ65mm
SCREW L/D: 30:1
HEATER CAPACITY: 16.5kw
DRIVING MOTOR: 37kw
3) DIE HEAD:
DIE DIAMETER: LDPE: Φ350mm HDPE: Φ90mm,Φ120mm
HEATER CAPACITY: 9.95 kw LDPE 6.1kw HDPE
COOLING AIR BLOWER: 5.5kw
4) HAUL-OFF:
DRIVING MOTOR: 2.2kw
TAKE-UP SPEED: 10-50 m/min
WINDER DRIVE MOTOR: 4.4kw
TEMPERATURE CONTROL: 6 units
WHOLE POWER WITH TOTAL MACHINE: 80kw
SHAPE SIZE: ~(L x W x H) 6.7X3.2X7.0m
Weight: ~5.2t
