Specifications
Good performance: automatically reversal winderSuperior quality and reasonable price
Features:
To achieve the high output performance of the Film blowing machine , it employs new technology such as automatically reversal winder. It is featured by more reasonable structure, few labor force, little waste and high speed. This line is special design for plastic film made of high density polyethylene (HDPE). The products are widely used in application of package of civil and industrial products such as food, garment, textile and daily necessities. The products include vest bag, shopping bag, garment bag and food bag etc.
I. Main Technology Parameters:
Model |
SJ45-FMS850H |
SJ55-FMS1100H |
SJ65-FMS1300H |
Max. Folded Film Width |
700mm |
1000mm |
1200mm |
Film Thickness |
0.008~0.15mm |
0.008~0.15mm |
0.015~0.20mm |
Output |
55 kg/h |
80 kg/h |
100 kg/h |
Raw Material |
HDPE |
||
Screw Diameter |
Φ45mm |
Φ55mm |
Φ65mm |
Screw L/D |
28:1 |
28:1 |
28:1 |
Total Power of the Machine |
~32KW |
~43 KW |
~55KW |
Shape Size( L x W x H) |
4.5X2.5 X 4.0m |
5.5 X 3.0X4.5m |
6.3 X3.5 X 5.5m |
Weight |
~2000kg |
~3000kg |
~3800kg |
Correct specifications depend on the actual model all specifications are subject to change without prior notice | |||
