Help CenterLatest High Speed PE Film Blowing Machine
Related Products
-
High Speed Plastic PE Film Blowing MachineNegotiableMOQ: 1 Set -
High Speed Plastic Film Blowing MachineNegotiableMOQ: 1 Set
-
High Output /Prolific PE Film Blowing Machine/ Film Blown Machine/Hdpe Film ExtruderNegotiableMOQ: 1 Set
-
High Speed PE Film Blowing MachineNegotiableMOQ: 1 Set
-
High Speed pe Plastic Blown Film MachineNegotiableMOQ: 1 Set
FEATURES
Our SJ-H Series High Speed Film Blowing Machine Lines own a lot of advantages: more compact structure, higher output, better quality, more energy saving, easy operating, which can be fit for producing all kinds of packing film, thereby create higher economical efficiency for you.
MAIN TECHNICAL PARAMETERS
SJ-H Series High Speed HDPE Film blowing machine | |||
Model |
SJ45-FMS850H |
SJ55-FMS1100H |
SJ65-FMS1300H |
Max. Folded Film Width |
700mm |
1000mm |
1200mm |
Film Thickness |
0.008~0.15mm |
0.008~0.15mm |
0.015~0.20mm |
Output |
55 kg/h |
80 kg/h |
100 kg/h |
Raw Material |
HDPE |
||
Screw Diameter |
Φ45mm |
Φ55mm |
Φ65mm |
Screw L/D |
28:1 |
28:1 |
28:1 |
Power of Main Motor |
15KW |
22 KW |
30KW |
Die Diameter |
HDPEΦ60mmΦ80mm |
HDPEΦ80mmΦ100mm |
HDPEΦ100mmΦ120mm |
|
Die Heater Capacity
|
3.45KW |
3.45 KW |
6.1 KW |
Cooling Air Blower |
2.2KW |
3.0KW |
4.0 KW |
Haul-off Driving Motor |
1.5 KW |
1.5KW |
1.5 KW |
Take-up Speed |
10~100m/min |
10~100m/min |
10~100m/min |
Winder Drive Motor |
2.2KW |
2.2 KW |
2.2 KW |
Temperature Control |
6 units |
6 units |
6 units |
Total Power of the Machine |
~32KW |
~43 KW |
~55KW |
Shape Size( L x W x H) |
4.5X2.5 X 4.0m |
5.5 X 3.0X4.5m |
6.3 X3.5 X 5.5m |
Weight |
~2000kg |
~3000kg |
~3800kg |
Correct specifications depend on the actual model all specifications are subject to change without prior notice. | |||
