SJ-H Series High Speed Plastic Film Blowing Machine

Name: SJ-H Series High Speed Plastic Film Blowing Machine
Brand: Donglong
SKU: 122547337

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Film

Plastic Processed:

Donglong Plastic Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Film

Plastic Processed PE

Blow Moulding Type Extrusion Blow Moulding

Automatic Yes

Place of Origin Fujian, China

Brand Name Donglong

Model Number SJ55-FMS1100H

Voltage 220V/380V

Power(W) 43kw

Dimension(L*W*H) 5.5*3.0*4.5m

Weight 3000kg

Certification ISO9001

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Features:

To achieve the high output performance of the blowing film, the film blowing machine/film blowing machines/film blowing machinery employs new technology such as automatically reversal winder.
This kind of film blowing machines is featured by more reasonable structure, few labor force, little waste and high speed. This film blowing machines line is special design for plastic film made of high density polyethylene (HDPE). The products are widely used in application of package of civil and industrial products such as food, garment, textile and daily necessities.The products include vest bag, shopping bag, garment bag and food bag etc.

Main technical parameters:

SJ-H Series High Speed Film Blowing Machine/Film blowing machines/film blowing machinery
Model	SJ45-FMS850H	SJ55-FMS1100H	SJ65-FMS1300H
Max. Folded Film Width	700mm	1000mm	1200mm
Film Thickness	0.008~0.15mm	0.008~0.15mm	0.015~0.20mm
Output	55 kg/h	80 kg/h	100 kg/h
Raw Material	HDPE
Screw Diameter	Φ45mm	Φ55mm	Φ65mm
Screw L/D	28:1	28:1	28:1
Power of Main Motor	15KW	22 KW	30KW
Die Diameter	HDPEΦ60mmΦ80mm	HDPEΦ80mmΦ100mm	HDPEΦ100mmΦ120mm
Die Heater Capacity	3.45KW	3.45 KW	6.1 KW
Cooling Air Blower	2.2KW	3.0KW	4.0 KW
Haul-off Driving Motor	1.5 KW	1.5KW	1.5 KW
Take-up Speed	10~100m/min	10~100m/min	10~100m/min
Winder Drive Motor	2.2KW	2.2 KW	2.2 KW
Temperature Control	6 units	6 units	6 units
Total Power of the Machine	~32KW	~43 KW	~55KW
Shape Size( L x W x H)	4.5X2.5 X 4.0m	5.5 X 3.0X4.5m	6.3 X3.5 X 5.5m
Weight	~2000kg	~3000kg	~3800kg
Design and specifications are subject to change without any notice.
