2kW/3kW/5kW wind turbine wind generator for home farm use

Specifications

15-20 years service life
Siemens PLC control module
Touch screen
Grid-tied and off-grid options
CE certificate, 7 patents

2kW/3kW/5kW wind turbine wind generator for home farm use Product Information

H6.4-5000W wind turbine features with unique design of structure, high output efficiency and stable operation of whole system.



Unique design

The structure of H6.4-5000W wind turbine is compact, which is made of refined material. The generator is small in size, light in weight that can be placed inside the nose cone to reduce air resistance and increase output efficiency.



High output efficiency

Due to the unique design, H6.4-5000W wind turbine can swiftly start up at 2.5m/s wind speed. The output efficiency of H6.4-5000W wind turbine is more than 0.8, while the wind energy utilization ratio is as high as 0.4. The max output of it is 7500W.



Stable operation of whole system

H6.4-5000W wind turbine without tail wing and tail pole, using Siemens control system, can realize functions of self protection, auto wind seeking etc.



Furthermore, inside the yaw shaft, there is a sealed gearbox, which can enhance the lifespan of whole system.

We can offer both off grid and grid-tied H6.4-5000W wind turbine systems.



Main technical data for wind power generator 5kw for communication station use

Rated power (W)	5000
Maximum output power (W)	7500
Battery bank voltage (Vdc)	240
System output voltage (Vac)	110/220/380
Start-up wind speed (m/s)	2.5
Rated wind speed (m/s)	10
Working wind speed (m/s)	3-25
Survival wind speed (m/s)	50
Generator efficiency	>0.8
Wind energy utilizing ratio (Cp)	0.4
Generator type	Permanent Magnet Alternator
Generator weight (kg)	147
Blade material/quantity	GRP/3
Blade diameter (m)	6.4
Speed regulation method	Yawing+Electromagnetism braking(Optional hydraulic braking)
Shutting down method	Manual+Automatic
