Help Center5kW Windmill 48V System 5000W for Communication Station
Related Products
-
5kW Wind Turbine Wind Power Generator Free Energy Generator for Home/farm/irrigation SystemUS$ 7,400 - 12,000MOQ: 1 Set -
Best Price 5kw Wind Turbines Horizontal ONLYUS$ 7,000 - 9,000MOQ: 10 Sets
-
Residential 48V 500W to 5kW Wind Energy Generator Wind Turbine GeneratorUS$ 7,400 - 12,000MOQ: 1 Set
-
High Power Wind Turbine Generator Wind Power Generator 5KWUS$ 4,000 - 8,000MOQ: 1 Set
-
5kW Wind Power Generator for SaleUS$ 3,000 - 8,000MOQ: 1 Set
Specifications
15-20 years service lifeSiemens PLC control module
Touch screen
Grid-tied and off-grid options
CE certificate, 7 patents
5kW windmill 48V system 5000W for communication station Product Information
H6.4-5000W wind turbine features with unique design of structure, high output efficiency and stable operation of whole system.
Unique design
The structure of H6.4-5000W wind turbine is compact, which is made of refined material. The generator is small in size, light in weight that can be placed inside the nose cone to reduce air resistance and increase output efficiency.
High output efficiency
Due to the unique design, H6.4-5000W wind turbine can swiftly start up at 2.5m/s wind speed. The output efficiency of H6.4-5000W wind turbine is more than 0.8, while the wind energy utilization ratio is as high as 0.4. The max output of it is 7500W.
Stable operation of whole system
H6.4-5000W wind turbine without tail wing and tail pole, using Siemens control system, can realize functions of self protection, auto wind seeking etc.
Furthermore, inside the yaw shaft, there is a sealed gearbox, which can enhance the lifespan of whole system.
We can offer both off grid and grid-tied H6.4-5000W wind turbine systems.
Main technical data for wind power generator 5kw for communication station use
| Rated power (W) | 5000 |
| Maximum output power (W) | 7500 |
| Battery bank voltage (Vdc) | 240 |
| System output voltage (Vac) | 110/220/380 |
| Start-up wind speed (m/s) | 2.5 |
| Rated wind speed (m/s) | 10 |
| Working wind speed (m/s) | 3-25 |
| Survival wind speed (m/s) | 50 |
| Generator efficiency | >0.8 |
| Wind energy utilizing ratio (Cp) | 0.4 |
| Generator type | Permanent Magnet Alternator |
| Generator weight (kg) | 147 |
| Blade material/quantity | GRP/3 |
| Blade diameter (m) | 6.4 |
| Speed regulation method | Yawing+Electromagnetism braking(Optional hydraulic braking) |
| Shutting down method | Manual+Automatic |
POWER CURVE
