China Hummer 20KW Wind Mills Internet Control

Name: China Hummer 20KW Wind Mills Internet Control
Brand: Hummer
SKU: 122483495

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Anhui, China

Brand Name:

Hummer

Model Number:

H9.0-20000W Windmill

Anhui Hummer Dynamo Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name Hummer

Model Number H9.0-20000W Windmill

Type Other, windmills

Specifications

-Smart control system
-Internet connect&PC remote control
-15 years life free maintain
-Smart turbine in the future

20KW Wind Mills

Features of hummer 20KW wind turbines :

1. SCF supercritical generator technology, generator weigh only 496kg, generation efficiency over 0.87.

2. Quality parts use SKF bearings and Siemens PLC control system and so on

3. Sine wave output, drive 6kw pump, 20kw appliances etc.

4. With protection functions of electronic yawing, electromagnetic break and dump load, even optional mechanical braking protection.

5. Connect with 6kw solar panels to make up the wind solar hybrid system.

6. High cost performance

7. Both off grid and grid tied wind turbines are available.

Application of Model H9.0-20000W

It can drive air-condition ( ≤20 horsepower), 6kw water pump or other resistive appliances (≤20KW).

Well used in:

Housing and factory and farm

Telecommunication Station

TV Transfer Station

Monitoring Station (military, hydrology, observatory)

Water-pumping Station

shipping

Main technical parameter

Rated power(W)	20000
Maximum output power(W)	28000
Charging voltage (V)	DC 240
Blade quantity	3
Rotor blade material	GRP
Rotor blade diameter (ft.)	30 (9.0m)
Start-up wind speed (mph)	7 (3.0m/s)
Rated wind speed (mph)	26 (11.5m/s)
Rated rotating rate (r/min)	180
Wind energy utilizing ratio (Cp)	0.40
Generator output	Frequency conversion AC
Rated charging current (A)	83.3
The maximum charging current (in a short time) (A)	120
Output AC frequency (Hz)	0~320
Generator efficiency	>0.87
Free standing tower diameter (in.)	Ø41.3Ø29.5 (1050750mm) (2 segment)
Tower height (ft.)	52 (16m)
The weight of generator(lb)	1093 (496kg)
Suggested Battery (Ah)	800/1000
