Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter

Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter thumbnail-1
Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter thumbnail-2
Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter thumbnail-3
Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter thumbnail-4
Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter thumbnail-5
Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter photo-1
Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter photo-2
Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter photo-3
Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter photo-4
Max Power 200w 800-2500MHz 2 Way Cavity Power Divider/ Splitter photo-5
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
kingtone
Model Number:
KT-514
Contact Supplier Request Quote Chat Now
Quanzhou Kingtone Optics & Electronics Technology Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name kingtone
Model Number KT-514

Quick Details

  • Place of Origin: Fujian, China (Mainland)
  • Brand Name: Kingtone
  • Model Number: KT-CPS2
  • Frequency: 800~2500MHz
  • Type: Cavity Power Splitter
  • Weight: 158g

Packaging & Delivery

Packaging Details: Each one into gift box;
Delivery Detail: 3~5days after received payment;

<:article id=richTextContainer>

Specifications



Power Splitter
Cavity type
800-2500Mhz
N connector



2 Way RF Power Splitter



Application:

1. Used in telecommunication application to split the one Input signal into two/three/four paths.

2. Widely used in In-building coverage applications.



Specification:

  • 800~2500MHz;
  •  VSWR≤1.2
  • Average Power: 200W
  •  Impedance=50Ω
  •  N-Female connector
  • Temperature= -30~65°C

Item Nos:



Type Item No. Net weight. Dimension. Insertion loss (dB) In-band Ripple(dB)
2 ways KT-CPS2  158g  210x60mm  ≤ 3.2  ≤ 0.4
3 ways KT-CPS3  181g  236x60mm  ≤ 5.2  ≤ 0.4
4 ways KT-CPS4  197g  236x60mm  ≤ 6.3  ≤ 0.5







Factory service

Our present manufacturing service:



1)  GSM/CDMA/WCDMA/IDEN/DCS/PCS/LTE and other Repeater, including:

1. Single band/

2. Dual band/

3. Tri band/

4. Optic Fiber/

5. Band or frequency selective

6. Band or Frequency Shifting

7. series Trunk Amplifiers.

2)All kind of GSM Repeater Accessories, including:

1.Antenna

2.Splitter

3.Connector

4.Cable

5.Functional Modules



3)Welcome to further discuss!!!  Provide telecom solutions!
