Home > Electrical & Electronics > Antenna > Communication Antenna > Kingtone 800-2700MHz 13dBi Yagi Antenna 2g 3g 4g Wide Band Yagi Antenna
Kingtone 800-2700MHz 13dBi Yagi Antenna 2g 3g 4g Wide Band Yagi Antenna
US$ 1 - 29
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
kingtone
Model Number:
Yagi-313135
Payment & Shipping
Payment Methods:
Port of Shipment:
XIAMEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
WCDMA 2100 3G Yagi Directional Antenna 3g 12dBi Yagi AntennaUS$ 1 - 29MOQ: 500 Pieces -
824-960 MHz 12~14 DBi Base Panel Directional Antenna, Repeater Antenna, Quality ChoiceUS$ 1 - 100MOQ: 2 Pieces
-
Wholesale Indoor Omnidirectional Ceiling Antennas Ceiling Antenna Indoor Celling AntennaUS$ 3 - 5MOQ: 100 Pieces
-
0.6m GSM Grid Parabolic Antenna 824-960 MHz 13dBI High GainUS$ 1 - 999MOQ: 2 Pieces
-
Professional 5dBi Omni-directional Outdoor Antenna(824-960 MHz)US$ 1 - 99MOQ: 50 Pieces
Place of Origin
Fujian, China
Brand Name
kingtone
Model Number
Yagi-313135
Kingtone 800-2700MHz 13dBi Yagi antenna 2g 3g 4g wide band yagi antenna
1.Picture of Product Kingtone 800-2700MHz 13dBi Yagi antenna 2g 3g 4g wide band yagi antenna
2.Specifications of the Kingtone 800-2700MHz 13dBi Yagi antenna 2g 3g 4g wide band yagi antenna :
Product Name |
806-960/1710-2700--13Dbi yagi antenna |
Electric Specification | |
Model NO |
Y313135 |
Frequency Range-MHz |
806-960/1710-2700 |
Gain-dBi |
13 |
beamwidth -° |
H:35 ; V:33 |
F/B Ratio |
≥15 |
VSWR |
≤2.0 |
Polarization |
Vertical |
Maximum Power-W |
100 |
Input Impedance-Ω |
50 |
Mechanical Specification | |
Connector |
N Female or customized |
Dimension-mm |
1200×185×55mm |
Weight-kg |
0.55Kg |
Working Temperature |
-40 to +60-℃ |
Material |
Aluminium |
Rated wind velocity |
60-m/s |
3.Standing Wave Pattern:
4. Radiation Pattern
