Specifications
Automatic pressure regulating system:no adjustment of cutting force.Directly from small to big cutting die.
USE AND CHARACTERISTICS
1. The machine is applicable to cutting of various nonmetal materials by cutting die.
2. Automatic pressure regulating system:no adjustment of cutting force.Directly from small to big cutting die.
3. High speed and low energy consumption.
4. Ductile cast iron body made the machine be used for a very long time and small noise.
5. 50% saving on cutting board costs.
6. Minimum operator fatigue.
Model |
GRT-S22 |
GRT-S27 |
GRT-S27K |
GRT-S27L |
Maximum cutting force |
22T |
27T |
27T |
27T |
Table area |
900×430mm |
1000×500mm |
1000×500mm |
1000×500mm |
Swing arm width |
370mm |
370mm |
500mm |
610mm |
Cutting stroke |
90mm |
90mm |
90mm |
90mm |
Motor power |
1.1KW |
1.5KW |
1.5KW |
1.5KW |
Electric Supply Voltage |
3x440/415/400/380 /220V, 50/60 Hz |
|||
Single phase 240V/220V, 50/60 Hz | ||||
Packing size |
1050×1000×1500mm |
1150×1200×1500mm |
1150×1200×1500mm |
1150×1200×1500mm |
N.W(with oil) |
650kg |
960Kg |
1050kg |
1200kg |
G.W |
740kg |
1120Kg |
1210kg |
1360kg |
REMARK:
1.The machine will include the PP cutting board(1000*500*30mm),hydraulic oil,tools,power line and spare parts.You can use the machine only coonect the power!
2.Our company may provide the Portuguese instructions.
3. I have the machine working video,please contact me if you need.
