Features
Automatically adjust the screen brightness by the light-sensor control system, power saved and environmentally friendly
High refresh rate and frame rate, vivid pictures
Change the advertisements at any time
Online power backup to ensure normal work
Remote networked control
Easy for installation,high transparency, low wind-resistance and waterproof
widely used in building showing
| Specification | RA-06 | |
| Optical parameters | Bringhtness(Nit) | 1500 |
| Grey scale(Bit) | 16 | |
| Color(Trillion) | 28.1 | |
| Color temperature(K) | 6500 | |
| Luminance angle(H/V) | 110°/ 110° | |
| View angle(H/V) | 150°/ 150° | |
| Contrast ratio | 5000:1 | |
| Malfunction dot rate | 0.1≤‰ | |
| Module parameters | Pixel configuration | 1R1G1B(8×8matrix) |
| Pixel pitch(MM) | 6 | |
| Module resolution | 32&32 | |
| Module size(MM) | 128*128 | |
| Module weight(G) | 390 | |
| Module voltage(V) | DC5 | |
| Module current(A) | 6.4 | |
| Module consumption(W) | 32 | |
| electrical parameters | Consumption(W/m2) | 840 |
| nsumption(W/m2) | 420 | |
| Input voltage(V) | AC90-240 | |
| Display performance | Driver method | 1/8 scan |
| Refresh rate | ≥600 | |
| Frame rate(Hz) | 50&60 | |
| Cabinet component | Cabinet resolution | 96*64 |
| Cabinet material | cast aluminium | |
| Cabinet size(MM) | 768*768*120mm | |
| Cabinet weight(Kg) | 10 | |
| Cabinet flatness(MM/m2) | ≤1 | |
| Usage parameters | MTBF(H) | 10000 |
| Lifespan(H) | 100000 | |
| Operation temperature(°C) | 0~50 | |
| Operation humidity | 10%~90% | |
Module
Cabinet
Screen
Application
Certificate
Factory operating & assembly
- Anti-shocking wooden case
- Flight case
- Carton-box
Control System Configuration
Foxgolden adopts the latest technology available on the market, based on its reliability and performance.
On the proScreen range only, Foxgolden can provide the Apple® Mac Mini® control PC instead of the default PC (upon request only). Apple® Mac Mini® is the world’s most reliable and energy-efficient desktop computer.
Here's technical specifications of the Apple® Mac Mini® mounted (upon request only) on your Foxgolden LED screen:
Installation
Our service:
1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English .
3.OEM&ODM, any your customized screen we can help you to design and put into product.
4.Distributoer ship are offered for your unique design and some our current models .
5.Protection of your sales area, ideas of design and all your private information .
Trade Terms:
1.Payment: T/T , 35% deposits before production, 65% balance to be paid before dleiverying (Western Union or Moneygram are welcomed)
2.Production lead time for 10~50pcs: 7days, 50~100pcs:15days
3.Sample can be delivered in 3days
4.Shipping freight are quoted under your requests
5.Shipping port: Shenzhen, Mainland China
6.Discounts are offered based on order quantities
7.MOQ:1m2
