300Mbps Wireless Repeater More Rage for Every WLAN Network

300Mbps Wireless Repeater More Rage for Every WLAN Network thumbnail-1
300Mbps Wireless Repeater More Rage for Every WLAN Network photo-1
US$ 10 - 12 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Lucktech or OEM
Model Number:
LK-WN518W2
Contact Supplier Request Quote Chat Now
Ningbo Lucktech Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Lucktech or OEM
Model Number LK-WN518W2

Specifications

wifi repeater
1,wireless 802.11n Standard
2,supports repeater,client an AP operation mode
3,Features a hardware WPS button

wifi repeater description:

The WiFi Repeater, also called range extander is used to broaden range of a wifi network. A wifi repeater works by receiving the Wifi signal from a router and then amplify and rebroadcast it around locally. With a wifi repeater Computers and printers that located out of the orginal range of access point can access the extended wifi network. Wifi repeater effectively doubles the coverage area of your existing Wifi network, extend your network to the far end of your home or office, you just need to place it half way between the computers and router.



Features:

• Improves wireless coverage in all WLAN networks
• WLAN 802.11n for wireless high-speed access
• Downward compatible with 802.11g(54Mbit/s) and 802.11b standard(11Mbit/s)
• Support 2.4GHz WLAN networks
• Maximum WLAN security with WPA2, WPA and WEP(128/64)
• Software wizard for simple setup
• Antennas integrated



Package Content:

1 x Wireless-N Repeater
1 x RJ-45 Networking Cable
1 x  Quick Installation



System Requitement:



• 110 ~ 230-volt socket
• The WLAN client must support at least the WPA encryption standard.
• WLAN access point and the WLAN client with automatic IP address assignment (DHCP)
• Forwarding of IPv4-based protocols/Address Resolution Protocol
• The network name (SSID) of the WLAN access point must be set to "visible".
• WLAN access point/client according to IEEE 802.11n, g, b.





SPECIFICATION
Hardware Wireless
Ports 1 x RJ45 Jack, Standard IEEE802.11b,IEEE 802.11g, IEEE 802.11n
Button Reset WPS Modulation 802.11b: DSSS / BPSK / QPSK / CCK
802.11g: OFDM / DSSS / BPSK / QPSK / CCK
802.11n: OFDM / DSSS / BPSK / QPSK / CCK
LED 1x LAN, 1 x WLAN, 1 x Power,1 x WPS,
Chipset RTL8196E Speed 802.11b : 11 Mbps;
802.11g : 54, Mbps
802.11n : 300Mbps
Flash 16Mbps
SDRAM 128Mbps Channel 11: (Ch.1-11) - USA
13: (Ch.1-13) – Europe
14: (Ch.1-14) – Japan
Power Supply Internal DC5V / 1A
Power Plug UK/EU/US/China/Australia (option) Frequency band 2.412~2.462 GHz –USA
2.412~2.472 GHz –Europe ETSI
2.412~2.484 GHz –Japan
Power Consumption 2.3W
Rated Voltage/ requency /current 100-240 Va.c. 50/60Hz, 0.1A Max , CLASSⅡ Power 802.11b: 17dBm ± 1.5 dBm
802.11g: 14dBm ± 1.5 dBm
802.11n: 14dBm ± 1.5 dBm
Dimensions
Unit Dimensions 95 x 65 x 50mm (L x W x H) Sensitivity 802.11b: -83dBm /802.11g: -70dBm / 802.11n: -68dBm
Weight About 109g Antenna 2 x 2dBi Integrated Antennas
Package Dimensions x x x MM   (xxg/PCS) Distance Outdoors 300m, Indoor 100m(According to the actual environment change)
Inner Pack x x x CM (xxPCS/CTN) Safely 64/128-bit WEP, AES,TKIP,WPA,WPA2,802.1x,WPA-PSK,WPA2-PSK,MAC , WDS
Master Carton x x x CM (xxPCS/CTN)
Environmental Software
Operating Temperature 0ºC~40ºC Standard Version RFC768 User Datagram Protocol(UDP)
RFC791 Internet Protocol(IP)
RFC792 Internet Control Message Protocol
RFC793 Transmission Control Protocol(TCP)
bandwidth:20MHz,40MHz,Automatic(option)
Wireless Mode:11n only,11 bgn mixed,11 bg mixed,11g only,11b only(option)
Storage Temperature -10~70°C
Relative Humidity(Operational) 10%~90%,noncondensing
Relative Humidity(Storage) 10%~90%,noncondensing
Certification
CE-EMC EN55022 EN55024          NO suitable   Mode AP Mode / Repeater Mode
CE-RTTE EN301489-1 V 1.9.2 EN301489-17 V2.1.1 EN300328 V 1.7.1 PASS
CE-LVD EN60950-1 PASS Wireless Safely Wireless MAC address Screening
Wireless security function switch
64/128/152-bit WEP
WPA-PSK/WPA2-PSK,WPA/WPA2
FCC DOC FCC Prat15 B PASS
FCC ID FCC Part15C PASS
ROHS 2011/65/EC PASS Function IP bandwidth control(Router mode support)
DNS Relay(Router mode support)
VPN Pass-through(Router mode support)
Static Router(Router mode support)
DHCP Server(Router mode support)
Reach SVHC-73 PASS
3C GB4943-2001 GB9254-1998 GB/T17618-1998 NOT
Others
Method See Manual
Performance See Test Report DHCP settings Server list(Router mode support)
Static IP address allocation (Router mode support)
Reliability See Test Report
