EXCEL 1000FT LSZH SOLID PURE COPPER CAT.6 UTP LAN CABLE WITH PURPLE COLOR

EXCEL CAT.6 UTP CABLE SOLID PURE COPPER LSZH PURPLE 1000FT

Cat 6  Ethernet cable, industry standard, purple jacket and supplied in cut lengths.
This is solid Copper, none of the Aluminium copper clad stuff!  (called CCA in the trade).

Features
 Category 6 compliant
LSOH outer sheath
 Central ‘X’ filler
 Backward Compatible
23AWG conductor
 Fast Feed Reelex Packaging
305-0’ metre marked
25 year system warranty
Independently component tested
No.4 cabling system by market share, as reported by BSRIA

Specification

• Overall Diameter 6.2mm
• Installation Temperature Range 0°C to +60°C
• Nominal Velocity of Propagation (NVP) 69%
• Operation Temperature Range -10°c to +75°c
• Bend Radius 4 x overall diameter installed, 8x during installation
• Cable weight 4.10 Kg/100m
• 305m Box Weight 13.2 Kg (inc. box)
• Box Dimensions 255mm wide x 415mm high x 415mm deep
• Standard of flame retardancy IEC 60332-1-[1,2] (2004-07)
• Cable jacket tested to IEC 62321, US EPA 3540C, BS EN 14582
