Help CenterWpc Extrusion Die Mould
Related Products
Specifications
1. High strength steel2.Good quality, thoughtful services
3. Precise details of proces
Mold Design:
Die has a streamlined flow channel surface, the two halves of the body mold design, die disintegration, easy to clean.
Manual trimming elastic modulus lip or movable upper die lip design to fit different thickness sheet extrusion requirements.
Vertical choke rod designed to suit different viscosity melt stream to obtain a uniform distribution.
Mold manufacturing:
Mold body using high-quality imported alloy tool steel, or to extend the life of the mold.
1.All channel surface hard chromium plating, the average thickness of 15μm ~ 50μm, and mirror-polished.
2. die fasteners 12.9 high strength bolts.
3. heating elements made of high quality, durable stainless steel heating rods, heating ring
Mold Features:
Molds for the production of pvc crust foam sheet.
Range :1-30mm plate thickness
Sheet width :500-1800mm
The first one 1980mmpvc skinning foam plate mold mold from Huangyan Jing Wei
Die advantages:
Pre-warm and attentive service, feel Jing Wei charm;
Sound and efficient after-sales service to solve your worries.
Name |
Extrusion coating die |
Usage for products |
Plastic film pvc |
Film thickness |
0.005-0.02mm |
Die width |
300mm-8000mm or per your request |
Die material |
2738 from Germany or P20 |
|
Lips adjustment system (for the upper die lip) |
1.Manual full push flexible fine-turning |
2.Automatic full push flexible fine-turning | |
3.Manual push & pull fine-turning | |
4.Automatic push & pull fine-turning | |
Wide-size adjustment method |
With the reduction of the thick edge, the inner block-type lead screw adjustment device can continuously adjust the die wide-size online to maximize the cost savings. |
Flow channel |
Branch-tube type |
Heat Voltage |
220V or on customer’s request |
Heating way |
Heating bars made of stainless steel from Italy |
Cable connection: |
Close connecting with protection cover |
Screws |
High strength at 12.9 grade |
Polishing |
Lips and surface of flowing: 0.02-0.03(μm),Other surfaces: 0.03-0.04(μm). |
Chrome thickness: |
0.035-0.045mm |
Surface hardness: |
60-70HR |
Feeding type: |
Round or square or special |
Installation |
On costumer’s request |
1. Packaging Detail:
Outside package: Standard export wooden cases;
Inner package: Bubble wrap.
2. Delivery Detail:
within 30 days,
Jing Wei is a company engaged in mold flat die extrusion, hydraulic screen changer, multilayer coextrusion line for 10 years for several companies.
Main products: all kinds of sheet die, die plates, cast film lamination mold, plastic plate mold, foam board mold, extrusion die plate, hollow grid plate die, hydraulic screen changer, quick change network devices, such as swing leaves coextrusion
Our commitment: meet the actual requirements, three packs of one year of normal production quality
Taizhou Huangyan Jingwei Mold Co.,Ltd.,a specialist manufacturer of flat extrusion dies,has engaged in the research ,development and manufacturing of extrusion plates,sheet film single layer or multilayer co-extrusion die,distributors,melt pump,hydraulic screen changer and etc.With the abundant manufacturing experience and continuously technical innovation ,equipped with moderm CNC processing machines ,our company is making the products to be much better.Our products are being widely used for PP.PE.APET,PETG,PS,HIPS,ABS,PC,PMMA,PVC,EVAand other materials,production.Our extensive manufacyuring experiences and constant technological as well as state-of-the-art machining centers ensure constantly-improving of die quality.
At Jingwei,every dies are customized to meet the most stringentdemand of customers.Our engineers will coordinate with each customer to attain the attain the optimized configuration and the best design.
Excellent quailty,fine reputation and perfect service are the unchanged mission of every jingwei people.In the coming days ,Jingwei will produce unsurpassed dies and delivery more value to our customers and partners than they have expected by offering top quality and perfect service.
