Pm2.5 Sensor Electronic Sensor Price

Name: Pm2.5 Sensor Electronic Sensor Price
Brand: Sinoder
SKU: 122059407

US$ 20 - 100 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Henan, China

Brand Name:

Sinoder

Model Number:

SNHV-H01

Zhengzhou Sinoder Indutech Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name Sinoder

Model Number SNHV-H01

Usage Other, weighting

Theory Resistance Sensor

Output Analog Sensor

pm2.5 sensor electronic sensor price

Product description:

1, fully sealed structure, with laser welding, good waterproof, dustproof.

2, good dynamic response, the overload ability strong, easy to install, easy to use.

3, can be used for large tonnage hopper scale, dynamic rail weighbridge, etc.

4, widely used in the continuous casting bag, tundish temperature weighing system.

Parameter

Model	SNHV-H01
Rated capacities(Emax)	5,10,20,30,50,60,100,150t
Sensitivity	2.0±0.002mv/v
Total error	±0.1percentF.S ±0.2 percent F.S
Creep(30min)	±0.1 percent F.S ±0.2 percent F.S
Zero balance	±1 percent F.S
TCO	±0.2 percent F.S/10℃
TC SPAN	±0.1 percent F.S/10℃
Input resistance	400±20Ω
Output resistance	350 ±3Ω
Insulation resistance	≥5000MΩ
Operating Temp Range	-10~+200℃
Limit Temp Range	-10~+250℃
Compensation Temp Range	-10~+200℃
Safe load limit	150 percent F.S
Over load limit	300 percent F.S
Recommend excitati	10V~12V DC
Maximumu excitation	15V DC
Protection Class	IP68
Construction	Alloy Steel
Cable	Length:2m(5-10t)12m(20t)14m(30t)16m(50-150t) Diameter: Φ6mm(5-10t)Φ8mm(20-150t)
