high power ultrasonic transducer

Model

SNHV-J01

Rated capacities(Emax)

1,2,3,5,10,15,20,25,30,40t

Sensitivity

2.0±0.002 mV/V

Total error

±0.1,±002 percentF.S

Creep(30min)

±0.03 percent
F.S

Zero balance

±1 percent
F.S

TCO

±0.02 percent
F.S/10℃

TC SPAN

±0.02 percent
F.S/10℃

Input resistance

750 ±10 Ω(ohms)

Output resistance

703± 2 Ω(ohms)

Insulation resistance

≥5000MΩ

Temperature range,compensated

-10~+40℃

Temperature range,operating

-30~+70℃

Maximum safe overload

150 percent
F.S

Ultimate overload

300 percent
F.S

Excitation,recommend

10~12 V DC

Excitation,maximum

15 V DC

Protection Class

IP67

Construction

Alloy Steel

Cable

Length:8m(1~15t),10m(20t), 12m(25t)
14m(30,40t)
Diameter:5mm(1~5t)6mm(10~40t)
