Small Ultrasonic Current Bone Conduction Transducer Price

Small Ultrasonic Current Bone Conduction Transducer Price thumbnail-1
Small Ultrasonic Current Bone Conduction Transducer Price thumbnail-2
Small Ultrasonic Current Bone Conduction Transducer Price photo-1
Small Ultrasonic Current Bone Conduction Transducer Price photo-2
US$ 20 - 100 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Sinoder
Model Number:
SNHV-J02
Contact Supplier Request Quote Chat Now
Zhengzhou Sinoder Indutech Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name Sinoder
Model Number SNHV-J02
Usage Other, weighting
Theory Resistance Sensor
Output Analog Sensor



small ultrasonic current bone conduction transducer price





Parameter



Model

SNHV-J02

Rated capacities(Emax)

5,10,20,25,30,50,60,75,100kg

Sensitivity

3.0±0.003mv/v

Total error

±0.05percentF.S

Creep(30min)

±0.02 percentF.S

Zero balance

±1 percentF.S

TCO

±0.02 percentF.S/10℃

TC SPAN

±0.02 percentF.S/10℃

Input resistance

750±10Ω

Output resistance

702±3Ω

Insulation resistance

≥5000MΩ

Temperature range,compensated

-10~+40℃

Temperature range,operating

-30~+70℃

Maximum safe overload

150 percent
F.S

Ultimate overload

250 percent
F.S

Excitation,recommend

10~12V DC

Excitation,maximum

15V DC

Protection Class

IP68

Construction

Alloy Steel



Cable

Length=L:8m(5~10klb),Diameter:5mm 12m(20~75klb),Diameter: 6mm

16m(100klb), Diameter: 6mm





small ultrasonic current bone conduction transducer pricesmall ultrasonic current bone conduction transducer pricesmall ultrasonic current bone conduction transducer price





small ultrasonic current bone conduction transducer price
