V Clamp Bag Filter
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, Filter Housing
Medium Material:
PP
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Other, Filter Housing
Medium Material
PP
Place of Origin
Shanghai, China
Brand Name
BOOCCA, BOOCCA
Model Number
BF-KM, BF-KM
Specifications
V clamp Bag FilterEnvironmental protection, high saved source
Max. operating flow: 1080m3/h
Description
Diifferent with the tranditional bag filter housing,V-clamp filter housing using a V clamp to fix the top cover and the housing body instand of bolts.
It is very convenient,and the cover can auto quickly open when you just need to turn round the handle.
Features and Advantage
1.Operating pressure: 7 bar
2.Fitting bag: 2# filter bag
3.Placed bag number: 2~5 bag.
4. Flow: 90~225 CBM/h
5.Material: SS 304 or SS 316
Specification
Model |
Bag No. |
Dimension (mm) |
Max. flow (m3/h) |
Flange |
BF-KM3 |
3 |
φ500 |
135 |
3”-4” |
BF-KM4 |
4 |
φ558 |
180 |
3”-6” |
BF-KM6 |
6 |
φ660 |
270 |
3”-6” |
BF-KM8 |
8 |
φ760 |
360 |
4”-8” |
