Competive Full Paper Equipment 1880 mm tissue paper making machine
Zhucheng Honest Industry and Trade Co., Ltd. is professional in supplying efficient products of tissue plant, egg tray plant, food machinery, environmental protection equipment etc and high technical service.
we are proud of our achievements in many tissue plant abroad with our wealth ofindustry experience
.Now we are not only supply all the machines,but also to be able to offer a turnkey tissue plant project, including the pulp preperation, tissue makine, converting process as well as the waste water recovery to save the fresh water consumption.
1. BASIC DATA OF TISSUE MACHINE
1.1 |
REEL TRIM : |
FROM 1200 TO 3500 (UP TO CUSTOMER) |
1.2 |
BASIS WEIGHT AT REEL: |
14 – 42gsm |
1.3 |
YANKEE SPEED |
200m/min |
| 1.4 | FURNISH | Virgin pulp, Recycle paper pulp or Mixing pulp |
1.5 |
CAPACITY |
2--10 TPD |
1.6 |
YANKEE STEAM PRESSURE |
Max 3Bar |
2. TECHNICAL DATA AND MAIN PARTS
-
Cylinder former with air suction for sheet formation quickly.
-
Cylinder mould with stainless steel fabric for good lifespan of over 12 months
-
Special design press roll for high efficiency dewater to reduce the machine vacuum request
-
Yankee hood with hot air for improve the impact drying efficience
-
Special doctor blade for getting excellent creping quality
-
Special reeling design for operation easily.
-
Automatic pneumatic control for couch roll, press roll, doctor blade and reel
Motor with Inverter for energy saving
Turn-key Projects and Auxiliary Systems
We can integrate with a very deep experience on the Turn-Key basis.
1. Customized projects and complete production lines designed according to customer needs.
2. Modification of existing machines with solutions to satisfy customer needs.
3. The machine can be supplied with the accessories using first class components.
4. We shall provide the G.A. drawing, foundation drawing and layout drawing after receiving the advance payment.
5. We have the professional installation team to provide erection/or erection supervision, commissioning, test-run and training for customer. The customer shall provide international flight ticket, local transportation vehicle, food, hotel accommodations and salary for our engineers.
6. Performance and Mechanical Guarantee shall be provided for 1 year from the successful commissioning or 1.5 years from the date of Bill of Lading.
We Sincerely invite you to visit our factory to inspect the machines before we shipping.Before shipping, we will spend more 2 weeks to test the machines with raw materials to double ensure the machines running stready.
Zhucheng Honest Industry And Trade Co. LTD is a professional manufacturer of tiolet paper making machines, paper tissue machines, food washing machines, Environmental Protection machines and other paper machines. we only produce high quality machine for the world. Choose us, you will be very successful!
If you like our products, please do not hesitate to contact me. We hope to have a good coopertaion with you soon!
