Using Recycled Paper Making Toilet Paper Machine, 5TPD Small Toilet Paper Making Machine Price Quality Choice

Using Recycled Paper Making Toilet Paper Machine, 5TPD Small Toilet Paper Making Machine Price Quality Choice photo-1
Using Recycled Paper Making Toilet Paper Machine, 5TPD Small Toilet Paper Making Machine Price Quality Choice photo-2
Using Recycled Paper Making Toilet Paper Machine, 5TPD Small Toilet Paper Making Machine Price Quality Choice photo-3
Using Recycled Paper Making Toilet Paper Machine, 5TPD Small Toilet Paper Making Machine Price Quality Choice photo-4
Using Recycled Paper Making Toilet Paper Machine, 5TPD Small Toilet Paper Making Machine Price Quality Choice photo-5
Using Recycled Paper Making Toilet Paper Machine, 5TPD Small Toilet Paper Making Machine Price Quality Choice photo-6
US$ 30,000 - 98,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
Used
Year:
2016
Product Type:
Toilet Tissue
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port China
Delivery Detail:
Delivery time depends on order quantity.
Condition Used
Year 2016
Product Type Toilet Tissue
Processing Type Other, Toilet jumbo roll machine
Place of Origin Shandong, China
Brand Name Honest
Model Number 2400mm
Voltage 380V or 440V
Power(W) 40KW
Dimension(L*W*H) 2700mm*12000mm*1700mm
Weight 60000Kg
Certification CE
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Using Recycled Paper Making Toilet Paper Machine, 5TPD Small Toilet Paper Making Machine Price

What production can our Small Toilet Paper Making Machine make?

With virgin pulp and recycled paper preparation process, toilet jumbo roll will be made of good quality.

Further, after converting process, toilet roll paper, napkin, kitchen will be the final production.

What is the basis data of our Toilet Paper Making Machine?


1.
Furnish
Virgin pulp, Recycle paper pulp or Mixing pulp
2.
Finish production
Jumbo roll for toilet, napkin and kitchen towel
3.
Trim at reel
2400mm
4.
Basis weight at reel
15—30 gsm
5.
Operation speed(Yankee cylinder)
200mpm
6.
Capacity
6 tons per day
7.
Yankee steam pressure
Max 3 bar



Main Features

• Cylinder former with air suction for sheet formation quickly

• Cylinder mold with stainless steel fabric for good life more an of over 12 months

• Special design press roll for high efficiency dewater to reduce the machine vacuum request

• Yankee hood with hot air for improve the impact drying efficiency

• Special doctor blade for getting excellent creping quality

• Special reeling design for operation easily.

• Automatic pneumatic control for couch roll, press roll, doctor blade and reel

• Motor with Inverter for energy saving



Certifications
Detailed Images

Machine Parts

Name: Cylinder former

Original: China

Cylinder former with air suction for sheet formation quickly

All parts touching pulp are made from Stainless steel

Main Features

Name: Cylinder mold
Original: China
Cylinder mold with stainless steel fabric for good life more an of over 12 months


Machine Parts

Name: Press roll
Original: China
Special design press roll for high efficiency dewater to reduce the machine vacuum request

Main Features

Name: Yankee Hood
Original:
China
Yankee hood with hot air for improve the impact drying efficiency
Special doctor blade for getting excellent creping quality
Special reeling design for operation easily.


Our Service

Pre-Sales Service

* Inquiry and consulting

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
