CUT-60 Inverter Air Plasma Cutter

Name: CUT-60 Inverter Air Plasma Cutter
Brand: zzwelder
SKU: 121787583
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

zzwelder

Model Number:

CUT-60

Zhangzhou Welder Technology Exploiting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name zzwelder

Model Number CUT-60

Input Voltage 380V

Usage It can cut stainless,cooper,cast iron and so on.

Certification ISO9001/CCC

Specifications

1.Max. cutting thickness(mm): 23
2.Air plasma cutter manufacturer
3.OEM is welcome

♣The CUT Air Plasma Cutter Characteristics:

1.High cutting speed and low cost; cutting speed increase to several time of autogenous
cutter.

2.PWM modulating technology, high frequency, portable, handiness and energy saving.
3.Narrow and smooth cut-edge; not necessary for re-processing.

4.Durable welder less consuming of welding accessories.

5.Adopting no-contact arc starting cutting technique(70,100,120)

6.Adopting contacting arc starting cutting technique(30,40,60)

7.Can cut many sort of metal such as stainless steel, alloy steel copper

♣CUT-60 Technical Data:

Model	CUT-60
Input Power Voltage (frequency)(V,HZ)	380±10%50/60 (three phase)
Rate Input Power Capacity(KVA)	7.9
NO-load VoltageV	236
Output Current Adjustment range(A)	20-60
Rated Output Voltage(V)	104
Rated Duty Cycle(%) (25°C)	60
No-load Consumption(W)	50
Arc-start Mode	Touch/un-touch
Efficency(%)	85
Power Factor(COSφ)	0.93
Weight(KG)	18
Measurement(mm)	480×205×295
Insulation Class	F
Protection Class	IP23
Exhaust	0.25
Max.cutting Thickness(mm)	23
