CUT-40 Inverter Plasma Cutting Machine

Name: CUT-40 Inverter Plasma Cutting Machine
Brand: zzwelder
SKU: 121787515

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

zzwelder

Model Number:

CUT-40

Zhangzhou Welder Technology Exploiting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name zzwelder

Model Number CUT-40

Input Voltage 220V

Rated Current 20-40

Dimensions 371*155*295

Usage It can cut many kinds of metals.

Certification ISO9001/CCC

Specifications

1.Plasma cutting machine manufacturer
2.OEM is available

Inverter Plasma cutting maching

1.High cutting speed and low cost; cutting speed increase to several time of autogenous
cutter.

2.PWM modulating technology, high frequency, portable, handiness and energy saving.
3.Narrow and smooth cut-edge; not necessary for re-processing.

4.Durable welder less consuming of welding accessories.

5.Adopting no-contact arc starting cutting technique(70,100,120)

6.Adopting contacting arc starting cutting technique(30,40,60)

7.This cutting machine can cut many sort of metal such as stainless steel, alloy steel copper.

♣CUT-40 Technical Data:

Mode	CUT-40
Input power Voltage (frequency)(V,HZ)	220±10%50/60 (Single-phase)
Rate Input Power Capacity(KVA)	4.8
NO-load VoltageV	230
Output Current Adjustment Range(A)	20-40
Rated Output Voltage(V)	96
Rated Duty Cycle(%) (25°C)	60
No-load Consumption(W)	40
Are-start Mode	Touch/un-touch
Efficiency(%)	85
Power Factor(COSφ)	0.93
Weight(KG)	9
Measurement(mm)	371×155×295
Insulation Class	F
Protection Class	IP23
Exhaust	0.17
Max.Cutting Thickness	12
