Radial drill DR32,DR40,DR50
DR32,DR40,DR50 Radial Drill
Technical Specification:
Specification |
DR50 |
DR40 |
DR32 |
Table size( mm) |
500×630 |
450×600 |
400×550 |
Spindle travel( mm) |
315 |
280 |
280 |
Max. drilling diameter( mm) |
50 |
40 |
32 |
Distance between spindle axis and column( mm) |
350-1600 |
300-1300 |
300-1000 |
Distance between spindle nose and working surface of base plate( mm) |
320-1220 |
300-1120 |
250-1000 |
Spindle taper( Morse No.) |
5# |
4# |
4# |
Range of spindle speeds( rpm) |
25-2000 |
32-2500 |
32-2500 |
Number of spindle speeds( step) |
16 |
16 |
16 |
Range of spindle feeds( mm/r) |
0.04-3.20 |
0.10-1.25 |
0.10-1.25 |
Number of spindle feeds( step) |
16 |
8 |
8 |
Distance of headstock horizontal movement( mm) |
1250 |
1000 |
700 |
Spindle motor power( kw) |
4 |
3 |
2.2 |
Net weight( kg) |
3500 |
2500 |
1600 |
Overall dimensions(L×W×H)( mm) |
2500*1070*2840 |
2100*900*2490 |
1760*800*2300 |
