LV2630 DOUBLE-COLUMN VERTICAL LATHE
LV2630 double-column vertical lathes are suitable for machining of all kinds of industries. It can make rough and accurate turning of external cylindrical surface, circular conical surface, head face, grooving, severance, etc.
CHARACTERISTICS:
1. Working table adopts hydrostatic guide way. The spindle is to use NN30 (Grade D) bearing and able to turn precisely, with good carrying capacity.
2. Gear case is to use 40 Cr gear wheel of gear grinding. It has high precision and little noise.
3. Both hydraulic parts and electrical equipment use famous-brand products in China, they have high reliability.
4. Plastic coated guide ways are wearable.
5. Centralized lubricating oil supplying is convenient.
6. Raster display is used in standard accessories.
7. Castings of lathe are to use lost foam foundry (short for LFF) technique. Castings are wearable with good quality and dealt by aging.
TECHNICAL SPECIFICATIONS:
Model |
LV- 2250 |
LV-2400 |
LV-2500 |
LV-2630 |
Max. turning diameter of vertical tool post (mm) |
2500 |
4000 |
5000 |
6300 |
Working table diameter (mm) |
2250 |
3200/3600/ 3700 |
4500 |
5700 |
Max. height of work-piece (mm) |
1600/2000/ 2500 |
2000/2500/ 3200 |
3150 |
4000 |
Max. weight of work-piece (t) |
10/20 |
35 |
50 |
50/80 |
Working table range of rotation speed (r/min) |
2~63 |
0.85~40 |
0.4~40 |
0.28~21.1 |
Working table step of rotation speed |
16 |
two-gears Stepless |
Stepless |
four-gears Stepless |
Horizontal travel of right tool post (mm) |
-15~1400 |
-15~2200 |
— |
-50~3350 |
Vertical travel of right tool post (mm) |
1000/1250/ 1400/1600 |
1000/1250/ 1400/1600/ 1800/2100 |
— |
2100 |
Horizontal travel of left tool post (mm) |
-15~1400 |
-15~2200 |
— |
-50~3350 |
Vertical travel of left tool post (mm) |
1000/1250/ 1400/1600 |
1000/1250/ 1400/1600/ 1800/2100 |
— |
2100 |
Main motor power (KW) |
55 |
55 |
75 |
110 |
