SHD-35S Double Column Semi Automatic Band Saw
The automatic and semi-automatic dual-column horizontal sawing machine series designed by our company is incorporated with advantages of many other manufactures, featuring reasonable structure, stable and reliable performance, and high precision. It is ideal equipment for sawing/cutting of medium/small lots.
Technical Specifications:
MODEL |
SHD-35S |
Cutting Capacity(mm) |
circular:350 rectangel:350W×350H |
Blade Speed(m/min) |
25/35/50/65/83 |
Blade Size(mm) |
34×1.1×4250 |
Motor Main(KW) |
3.0(4P) |
Motor Hydraulic(KW) |
0.75 |
Coolant Pump(KW) |
0.075 |
Workpiece Clamping |
Hydraulic Vice |
Blade Tensioning |
Manual |
Main Drive |
Wormwheel Drive |
Table Height(mm) |
620 |
Size Outward(L×W×H)(mm) |
2120×1200×1560 |
Standard Equipment:
1 Blade cleaning brush
2 Working light
3 Saw frame height selector gauge
4 Out feed with auxiliary plate table
5 Length stopper
6 One piece of bi-mental saw blade
7 One set of tools with tool box
8 Roller table 1M long
Optional Equipment:
1 Variable vice pressure
2 Power roller table 2M long
3 Laser projector
4 Hydraulic blade tension
5 Roller table 2M long
Details:
