EPS Sandwich Panel Making Machine
Machine
Panel
Install
Main Technical Specification
Size: 38000mm × 3600mm × 3300mm
Total weight: about 24000KG
Controlling system: PLC
Total power(including heating):about 40KW
Working speed: 1000~3000mm/min
Density of EPS:>18kg/mm
Suitable material for production: 1000~1200mm × (0.5~0.6mm)
The Work Flow Of Sandwich Panel Line
Decoiling: Feeding of the material for bottom metal strip
Roll Forming: Producing the Bottom metal strip for roof/wall panel
EPS Feeding Table: Placing the middle part of the sandwich panel
Dripping glue onto top and bottom metal strips
Heating of strips for better adhesions of glue
Rolling edges of the strips
Connecting parts and roll forming together
Making slot (milling cutting to cut extra parts of EPS) of panels for specific length
Confirming length
Cutting adjusted by PLC
Shipping Terms:FOB Dalian,CIF,CFR
Introduce
Our Company
Our Certificates
Our Customers
Q:Wy I choose your company?
A:Our company was established in 1992,export experience about 20 years.We can ensure the machine quality and price.
Q:Can you accept OEM?
A:We can accept OEM.
Q:Can you produce machine as our requirement?
A:Sure,we have professional and development personnel,if you provide the relevant information,we can produce.
Q:Can you pay on delivery?
A:No,but if the amount is big,you can pay the deposite first,the balance before our shipment.
Q:What is your MOQ?
A one set.
Payment term: T/T ,30% deposit in advance,the balance 70% before our shipment.
Delivery time: Within 30 workdays after receiving 30% deposit.
Warrantee period:3 years.During 3 years, all the damaged parts can be changed into new ones only if the buyer sends the damaged ones back, but the express cost is afforded by the buyer(man-made damage is not included).
Training: If the buyer needs us to go to the project site abroad for training, the buyer affords the ticket, visa, hotel and meals, and the salary $150/day/person. The training period has to be within 15 days.
