Help CenterTwo Wave Panel Guard Rail Forming Machine
Related Products
-
Glazed Tile Roof Sheet Arch MachineUS$ 18,000 - 45,000MOQ: 1 Set -
STEEL COLD ROLL FORMING MACHINEUS$ 10,000 - 30,000MOQ: 1 Set
-
Roof and Wall Panel Roll Forming MachineUS$ 1,000 - 100,000MOQ: 1 Set
-
Double Layers Flat Roof Sheet Making MachineUS$ 4,000 - 18,000MOQ: 1 Set
-
Sanxing Glazed Tile Corrugated Roll Forming MachineUS$ 20,000 - 30,000MOQ: 1 Set
About our company
We are specialized in producing W purline fast guardrail roll forming machine, including coiler machining, cold roll forming machine, automatic product line etc. We had supplied thousands of machines to domestic and foreign countries, such as environmental protection, automobile, steel, warehouse, and logistics industry.
About the guard rail forming machine
The guardrail forming machine,also called the highway guardrail former,is used to make corrugated steel beams,guard rails and sign posts applications to locate along highways,streets or minor roads.
The form can be linear,V or W shape and many others.This machine has simple structure and good performance offering good capability working safely and reliable .The guard rail forming machine is highly automatic producing panels smoothly.
New innovations and continuously increasing efficiencies with the right guard rail forming,can make any company's manufacturing process a profitable business.The complete line of guard rail forming
machine includes electric decoiler,automatic hydraulic punching system,feeding and guiding part,
leveling device,forming roller system,hydraulic cutting,stacking table and PLC control board.
Since 1990,Sanxing Group has provided guard rail forming machine soulutions to the building and construction industry and for the atomotive field around the world.Welcome to contact us for further
information about our machines.
1.Rolling materials: 480mm wide, 2.0mm~4.0mm thick,, Q235A galvanized steel sheet
2.Working speed: 10-12 m/min
3.Number of rollers: 17 main rollers (2 transportation) and 7 leveling rollers
4.Materials of rollers: Gcr15 hardened bearing steel, HRC58-62
5.Materials of main shaft: 45# high quality quenched steel
6.Diameter of main shaft: 100mm
7.Main motor power: 30kw
8.Driving mode: cardan joint gear casing drive
9.Leveling motor power:22kw
10.Hydraulic motor power:15kw, 20Mpa
11.Punching and cutting: hydraulic driving, plate punching, cutting after molding
12.Electric control system: The machine is adopted industrial PLC frequency control, cut length error:2mm
13.Dimensions (mm): 14500*1500*1600
14.Materials of molding blade: Cr12
15.Cut-length: 10m approximate
Processing flow
Loading—decoiler—leveling loading—punching—forming –cutting –output
