FEATURES
1. In order to meet the requirements to use all kinds of colored sheet and materials (high and low strength sheet), our company improves the design of the forming press and adds a herringbone roller between wave crests of profile, which makes pressed sheet flat, beautiful appearance and increase the strength of the flat sheet.
2. All the rollers are forged from the high quality steel and are processed intensely through high frequency hardening and quenching and tempering. The surfaces of the rollers are plated with hard chromium. The rollers are smooth and wear proof.The computer controls the length and the measurement, which is reliable and laborsaving.
Configurations
Manual Uncoiler--Roll Forming Machine--Cutting Device---
Hydraulic Station ---PLC Control---Exit rack.
Techinial Parameters
De-coiling device: Manual, 5T
Motor power: 3 kw
Hydraulic motor power: 3kw
Quantity of roll stand: 8
Material of blade: Cr12,quenched
Thickness of coil: 0.3~0.8mm
Forming speed: 8-12 m/min
Material of roller: high grade 45# steel ,plated hard chromed
Controlling: PLC
1) Three years guarantee for whole machine except of bearing parts.
2) 24 hours technical support by e-mail.
3) Use-friendly English manual and videos.
Yingkou Sanxing Roll Forming Machine Co.Ltd forcus on steel building machine since 1992. The earliest arch steel forming machine manufacture with engineering qualification in China. So not only we are professional in machine manufacturing but also experienced in projects. Please we are the best selection.
1. Is Sanxing Roll Forming Machine Co.Ltd factory or trader?
Surely, we are the factory with 20000 square meters area, including desinging,producing and marketing.
2. Discount ?
We could offer you the best machine with a good price.
3. Where to see machines?
We highly welcome you visit us anytime. You will see machines and project sample at the facotry.
4. Contact me
Ailsa
Mob. +86 13840720307
Skype:sanxing05
